| DESIGN | |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Antenna type | Internal |
| LED indicators | Yes |
| Product colour | White |
| Operating temperature (T-T) | Yes |
| Reset button | Yes |
| Product type | Mesh system |
| Maximum coverage | 650 m² | FEATURES |
| Firewall security | SPI Firewall |
| Quality of Service (QoS) support | Yes |
| DHCP client | Yes |
| DHCP server | Yes |
| Number of guest networks (5 GHz) | 1 |
| Number of guest networks (2.4 GHz) | 1 | LOGISTICS DATA |
| Harmonized System (HS) code | 85171800 | OPERATIONAL CONDITIONS |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90% | PACKAGING CONTENT |
| AC adapter included | Yes |
| Ethernet cable | Yes |
| Number of products included | 3 pc(s) |
| Number of adapters included | 3 pc(s) |
| Number of units included | 3 pc(s) | PORTS & INTERFACES |
| Ethernet LAN (RJ-45) ports | 3 |
| DC-in jack | Yes | PROTOCOLS |
| DHCP client | Yes |
| DHCP server | Yes | TECHNICAL DETAILS |
| Harmonized System (HS) code | 85171800 | WEIGHT & DIMENSIONS |
| Height | 83.7 mm |
| Width | 128 mm |
| Depth | 81 mm | WIRELESS LAN FEATURES |
| Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 4 (802.11n) |
| Security algorithms | WPA2-PSK, WPA3, WPA-PSK |
| Networking standards | IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11v, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g |
| Guest access | Yes |
| Static IP | Yes |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| WLAN data transfer rate (max) | 3000 Mbit/s |
| WLAN data transfer rate (first band) | 574 Mbit/s |
| WLAN data transfer rate (second band) | 2402 Mbit/s |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Point-to-point protocol over Ethernet (PPPoE) | Yes |
| Dynamic IP | Yes |
| Number of guest networks (5 GHz) | 1 |
| Number of guest networks (2.4 GHz) | 1 |
