Supports 3rd-Party Drives:
UGREEN NASync is widely compatible with third-party hard drives, including those from Western Digital, Seagate, Toshiba, and more.
Much Better Way to Store Than External Drives:
NAS offers centralized storage, automatic backups, remote access, and a wide range of RAID options for easy data recovery even if a drive fails.
Massive Storage Capacity:
Never worry about storage limits again. With up 136TB capacity, you can store 39 million photos or 76,000 movies!
Ultra-Fast Transfers:
Back up 1GB in less than 1 second using the 10GbE network port, with an additional 2.5GbE port available too.
Secure Private Cloud:
Retain 100% data ownership with advanced encryption to protect your files. Flexible permission management makes it easy to protect your privacy when collaborating with others.
AI Photo Album:
Automatically organizes your photos by recognizing faces, scenes, objects, and locations. It can also instantly remove duplicates, freeing up storage space and saving you time.
User-Friendly App:
Simple setup and easy file-sharing on Windows, macOS, Android, iOS, web browsers, and smart TVs, giving you secure access from any device.
2-Year Warranty:
Enjoy 2 years of protection with UGREEN.
Easy Access from Anywhere
Access and manage your stored files from anywhere with an internet connection. Combine the security of local storage with the convenience of remote access and effortless sharing. Great for everyday storage, home media libraries, or small businesses.
Cost-effective
UGREEN NAS is the smartest long-term way to store. Unlike with cloud storage, there are no ongoing subscription fees, and you can upgrade your storage capacity flexibly as you require it.
Broad Compatibility
UGREEN NAS is compatible with an extremely wide range of storage drives, including 3.5"/2.5" SATA drives and M.2 SSDs. All the most popular hard drive brands are supported, and there is no vendor lock-in of any kind.
The Highest-Funded NAS Product on Kickstarter
On Kickstarter, the UGREEN NASync series has garnered support from over 13,000 backers, raising $6.6 million and becoming the highest-funded NAS product on Kickstarter, earning the "Best of Kickstarter" award.
Your 4K Home Media Hub
Store all your movies in one place and automatically sort and classify them. Connect an HDMI cable to enjoy stunning 4K 60Hz playback with family and friends.
Specs
Model
DXP4800 Plus
Supported Language
English, Deutsch, Francais, Espanol, Portugues, Italiano
Drive Bays
4-Bay (SATA)
Operating System
UGOS Pro
CPU Model
8505
CPU Brand & Architecture
Intel X86 12th Generation Intel Pentium Gold 5 Cores 6 Threads
Memory (RAM)
8GB DDR5
ODECC
Supported
Expandable RAM (max)
64GB
Flash Memory (System Disk)
SSD 128GB
SATA Drive Bays
4
M.2 SSD Drive Slots
2
RAID
JBOD/Basic/0/1/5/6/10
Maximum Storage
136TB (4x 30TB + 2x 8TB)
LAN Ports (RJ45)
1x 2.5GbE, 1x 10GbE
PCIe Expansion
None
Thunderbolt™ 4 Ports
None
High-Speed USB Ports (Front Panel)
1x USB-C, 1x USB-A (both 10Gb/s)
High-Speed USB Ports (Rear Panel)
1x USB-A (5Gb/s)
USB 2.0 (Rear Panel)
2x USB-A (480Mb/s)
SD Card Reader
SD 3.0
HDMI
4K
Wi-Fi
None
Product Dimensions
10.1" x 7.0" x 7.0"
Power Consumption
42.36 W (drive access)
18.12 W(drive hibernation)
Warranty:
Manufacturers Warranty - For further details please visit the manufacturers website.
|
DESIGN
|
| Chassis type |
Desktop |
| Chassis type |
BTRFS, FAT32, HFS+, NTFS, exFAT, ext4 |
| Country of origin |
China |
ENERGY MANAGEMENT
|
| Power supply location |
Built-in |
LOGISTICS DATA
|
| Country of origin |
China |
MEMORY
|
| Internal memory type |
DDR5 |
| Memory slots |
2 |
| Memory form factor |
SO-DIMM |
| Maximum RAM supported |
64 GB |
| Internal memory |
8 GB |
NETWORKING
|
| Ethernet LAN |
Yes |
| DHCP server |
Yes |
| Ethernet LAN data rates |
2500,10000 Mbit/s |
| iSCSI support |
Yes |
OTHER FEATURES
|
| Warranty period |
2 year(s) |
PACKAGING CONTENT
|
| External power adapter |
Yes |
PERFORMANCE
|
| Type |
NAS |
| Buzzer |
Yes |
| Snapshot |
Yes |
| Web-based management |
Yes |
| Multilingual support |
Yes |
| On/off switch |
Yes |
| S.M.A.R.T. support |
Yes |
| Remotely operated |
Yes |
| Device class |
Home & Home Office |
| Backup function |
Yes |
| Backup features |
Cloud, USB drive, iSCSI LUN |
| System log |
Yes |
| Password authentication |
Yes |
| Disk scan |
Yes |
| Share folder access right management |
Yes |
| Third-party support |
Yes |
PORTS & INTERFACES
|
| USB 2.0 ports quantity |
2 |
| Ethernet LAN (RJ-45) ports |
2 |
| HDMI ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
PROCESSOR
|
| Processor manufacturer |
Intel |
| Processor family |
Intel® Pentium® |
| Processor cores |
5 |
| Processor threads |
6 |
SOFTWARE
|
| Operating system installed |
UGOS Pro |
STORAGE
|
| RAID levels |
0, 1, 5, JBOD |
| Supported file systems |
BTRFS, FAT32, HFS+, NTFS, exFAT, ext4 |
| RAID support |
Yes |
| Storage drive size |
M.2/2.5"/3.5" |
| Storage drive interface |
Serial ATA, Serial ATA III |
| Number of storage drives supported |
4 |
| Storage drive sizes supported |
2.5,3.5,M.2 |
| Storage drives installed |
No |
| Maximum supported storage capacity |
136 TB |
| Number of storage drives installed |
0 |
| Installed storage drive type |
HDD+SSD |
| Supported storage drive types |
HDD & SSD |
| Hot-swap drive bays |
Yes |
| Supported storage drive interfaces |
M.2, Serial ATA III |
| Auto-rebuild |
Yes |
| Online RAID migration |
Yes |
| Online RAID expansion |
Yes |
| Bad block scan |
Yes |
| Number of M.2 (M & B) slots |
2 |
| RAID rebuild |
Yes |
| Total installed storage capacity |
0 TB |
TECHNICAL DETAILS
|
| Chassis type |
BTRFS, FAT32, HFS+, NTFS, exFAT, ext4 |
