Mercusys MB115-4G 300 Mbps Wireless N 4G LTE Router

4G network
Share internet access with up to 32 Wi-Fi devices and enjoy download speeds of up to 150 Mbps

Plug a SIM card and play
No configurations needed, compatibility of SIM cards are assured by years of field tests

300 Mbps WiFi
Fast WiFi speeds up to 300 Mbps to share your network

Maximum Network Coverage
Enjoy stable and efficient connections to every device thanks to the four external antennas
Wi-Fi router mode – Plug an Ethernet cable into the LAN/WAN port for flexible access if you can't get a 4G connection
*Notes: Make sure your SIM card is unlocked.

WirelessWireless Standards
IEEE 802.11b/g/n

Frequency
2.4 GHz

Signal Rate
300 Mbps

Reception Sensitivity
11g 54M: -74.5 dBm
11n HT20 MCS7: -73.5 dBm
11n HT40 MCS7: -70.5 dBm

Transmission Power
< 20 dBm (2.4 GHz)

Wireless

Security
WPA-PSK / WPA2-PSK

Wireless Functions
Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless
Statistics

Software

DHCP
Server

Hardware

Dimensions (W X D X H)
219 x 140 x 32 mm
(8.62 x 5.51 x 1.26 in)

Interfaces
1x 10/100Mbps LAN/WAN Port
3x 10/100Mbps LAN Ports
1x Nano SIM Card Slot

Button
WPS
Reset Button

Ethernet Ports
1x 10/100 Mbps LAN/WAN Port
3x 10/100 Mbps LAN Ports

Network Type
EU:
FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz)
TDD-LTE: B38/B40 (2600/2300 MHz)
HSPA+/UMTS: B1/B5/B8 (2100/850/900 MHz)

Others

Package Contents
300 Mbps Wireless N 4G LTE Router (MB115-4G)
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide

Environment
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~60°C (-40°F~140°F)

Operating Humidity: 10%~90% Non-Condensing

Storage Humidity: 5%~90% Non-Condensing

Manufacturer's Website:

www.mercusys.com

Warranty:

3 Year Return To Base Warranty

Return-to-Base warranty returns are processed within 14 business days of confirmed date of receipt - see our Returns Policy for more information.

ANTENNA
Antennas quantity	4
Antenna design	External
DESIGN
Product colour	Black
Product type	Tabletop router
MANAGEMENT FEATURES
Reset button	Yes
WPS push button	Yes
Wi-Fi Multimedia�(WMM)/(WME)	Yes
MOBILE NETWORKING
3G bands supported	850,900,2100 MHz
SIM card type	NanoSIM
4G bands supported	700,800,850,900,1800,2100,2300,2600 MHz
4G standard	LTE-TDD & LTE-FDD
Mobile network generation	4G
NETWORKING
Ethernet LAN	Yes
Ethernet LAN data rates	10,100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Maximum Tx power (2.4 GHz)	74.5 dBmW
OPERATIONAL CONDITIONS
Operating relative humidity (H-H)	10 - 90%
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90%
PACKAGING CONTENT
AC adapter included	Yes
Cables included	LAN (RJ-45)
Quick installation guide	Yes
PACKAGING DATA
AC adapter included	Yes
Cables included	LAN (RJ-45)
Quick installation guide	Yes
PORTS & INTERFACES
Ethernet LAN (RJ-45) ports	4
POWER
Power source type	DC
PROTOCOLS
DHCP server	Yes
SECURITY
Security algorithms	WPA-PSK, WPA2-PSK
WAN CONNECTION
Ethernet WAN	Yes
WEIGHT & DIMENSIONS
Height	32 mm
Width	219 mm
Depth	140 mm
WIRELESS LAN FEATURES
Wi-Fi band	Single-band (2.4 GHz)
WLAN data transfer rate (max)	300 Mbit/s
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
