| Ports | 24 |
| Managed/Unmanaged | Managed |
| Ports | 24 |
| Managed/Unmanaged | Managed |
| CERTIFICATION | |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS | DATA TRANSMISSION |
| MAC address table | 32000 entries |
| Switching capacity | 200 Gbit/s |
| Jumbo frames support | Yes |
| Number of queues | 8 |
| Store-and-forward | Yes |
| Forwarding rate | 148.8 Mpps |
| Packet buffer memory | 16 MB |
| Number of static routes | 48 |
| Number of IP interfaces | 32 |
| Jumbo frames | 9000 |
| Static route | Yes | DESIGN |
| Rack mounting | Yes |
| Form factor | 1U |
| LED indicators | Yes |
| Product colour | Black |
| Number of fans | 3 fan(s) |
| Redundant fans support | Yes | ENERGY MANAGEMENT |
| Power source | AC/PoE |
| Redundant power supply (RPS) support | Yes |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Power consumption (max) | 629.1 W |
| Power supply included | Yes | MANAGEMENT FEATURES |
| MIB support | RFC1213, RFC2233, RFC1643, RFC1493, RFC2674, RFC2819, RFC2021, RFC2620, RFC2618, RFC2925 |
| Switch layer | L2+ |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| System event log | Yes |
| Switch type | Managed |
| ARP inspection | Yes |
| Configuring Location Settings (CLI) | Yes |
| Cloud-managed | Yes | MULTICAST FEATURES |
| Multicast support | Yes |
| Multicast Listener Discovery (MLD) snooping | MLD v1/v2 | NETWORKING |
| Full duplex | Yes |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Flow control support | Yes |
| Port mirroring | Yes |
| Link aggregation | Yes |
| Broadcast storm control | Yes |
| Rate limiting | Yes |
| Ethernet LAN data rates | 10,100,1000,2500,10000 Mbit/s |
| Spanning tree protocol | Yes |
| Head-of-line (HOL) blocking | Yes |
| VLAN support | Yes |
| 10G support | Yes |
| Virtual LAN features | MAC address-based VLAN, Port-based VLAN, Protocol-based VLAN, Stacked VLAN, Tagged VLAN, Voice VLAN |
| Half duplex | Yes |
| IPv4 routes | 48 |
| IPv6 routes | 48 | OPERATIONAL CONDITIONS |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Heat dissipation | 2153.45 BTU/h | PACKAGING CONTENT |
| Cables included | AC |
| Quick start guide | Yes |
| Rack mount kit | Yes | PACKAGING DATA |
| Cables included | AC |
| Quick start guide | Yes |
| Rack mount kit | Yes | PERFORMANCE |
| Internal memory | 256 MB |
| Flash memory | 32 MB |
| Memory type | DRAM | PORTS & INTERFACES |
| Console port | RJ-45/Micro-USB |
| Installed SFP+ modules quantity | 0 |
| Installed SFP modules quantity | 0 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| SFP+ module slots quantity | 4 |
| 2.5G Ethernet (copper) ports quantity | 24 | POWER OVER ETHERNET (POE) |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 16 |
| Total Power over Ethernet (PoE) budget | 500 W |
| Power over Ethernet 4PPoE (PoE++) ports quantity | 8 | PROTOCOLS |
| Management protocols | SNMP v1/v2c/v3 |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| IPv4 & IPv6 features | IPv4/IPv6 access-control list (ACL), IPv6 ping, IPv6 portal, IPv6 tracert | SECURITY |
| Security algorithms | HTTPS, SSH, SSH-2, SSL/TLS |
| Static port security | Yes |
| Access Control List (ACL) | Yes |
| SSH/SSL support | Yes |
| IGMP snooping | Yes |
| Authentication type | AAA, IEEE 802.1x, RADIUS, TACACS+ |
| Password protection | Yes |
| Loop protection | Yes |
| BPDU filtering/protection | Yes |
| IP-MAC-Port binding | Yes |
| Authentication | Guest VLAN, MAC-based authentication, Port-based authentication |
| Queue scheduling algorithms | SP, WRR+SP, Weighted Round Robin (WRR) |
| DHCP features | DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping | SUSTAINABILITY |
| Sustainability compliance | Yes | TECHNICAL DETAILS |
| Sustainability compliance | Yes |
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS | WEIGHT & DIMENSIONS |
| Height | 44 mm |
| Width | 440 mm |
| Depth | 330 mm |
