Target Components Ltd

AMD Ryzen 3 3200G: RYZEN Powers. RADEON Reigns. You Prevail

AMD GameCache - More Memory On-Chip to Accelerate Gaming
Up to twice the cache of previous generations, GameCache is designed to reduce memory latency for higher frame rates in top titles.

Precision Boost 2 - Boost performance when you need it
Precision Boost 2 automatically raises processor frequencies for supercharged performance when you need it most.

One Click Overclocking
Precision Boost Overdrive uses your motherboard's robust design to boost clock speeds higher and longer, and lets you overclock at the touch of a button.

AMD StoreMI Technology
Software that combines the speed of your SSD with the capacity of your hard disk into a single, fast, easy-to-manage drive - included with an AMD X570, 400 Series, or X399 motherboard.

AMD Ryzen Master Utility
Unlock ultimate control over your AMD Ryzen powered system for personalized overclocking and efficiency.

AMD Wraith Stealth
All AMD Ryzen 3 3200G processors come boxed with the efficient Wraith Stealth Cooler as standard, giving you an optimal thermal solution straight out of the box.

Specifications

Platform
Boxed Processor

Product Family
AMD Ryzen Processors

Product Line
AMD Ryzen 3 Desktop Processors with Radeon Vega Graphics

# of CPU Cores
4

# of Threads
4

Max. Boost Clock
Up to 4.0GHz

Base Clock
3.6GHz

L1 Cache
384KB

L2 Cache
2MB

L3 Cache
4MB

Default TDP
65W

AMD Configurable TDP (cTDP)
45-65W

Processor Technology for CPU Cores
12nm FinFET

Unlocked for Overclocking
Yes

CPU Socket
AM4

Thermal Solution
Wraith Stealth

Max. Operating Temperature (Tjmax)
95°C

Launch Date
7/7/2019

PCI Express Version
PCIe 3.0 x8

System Memory Type
DDR4

Memory Channels
2

System Memory Specification
Up to 2933MHz

Graphics Model
Radeon Vega 8 Graphics

Graphics Core Count
8

Graphics Frequency
1250 MHz

Manufacturer's Website:

www.amd.co.uk

Warranty:

AMD Processors in a box (PIB): 3 Year Limited Manufacturer Warranty.

Coverage

Year 1: Return to Target or AMD for warranty service.

Years 2-3: Warranty service provided directly by AMD

AMD Warranty Support

AMD Warranty Portal: https://www.amd.com/en/registration/warranty-services-portal.html

Please Note: First-time users must create an AMD account to access warranty services.

AMD Help & Support: https://www.amd.com/en/support.html

Required Documentation for AMD Warranty Claims

1. Product details including serial number and model number.

2. Clear explanation of the problem you're experiencing

3. Proof of purchase (receipt or invoice).

4. Photo of the CPU

ENERGY MANAGEMENT
Thermal Design Power (TDP)	65 W
FEATURES
Market segment	Desktop
Harmonized System (HS) code	85423119
Thermal Design Power (TDP)	65 W
GRAPHICS
On-board graphics card model	AMD Radeon Vega 8
Discrete graphics card model	Not available
On-board graphics card	Yes
On-board graphics card dynamic frequency (max)	1250 MHz
Discrete graphics card	No
On-board graphics adapter model	AMD Radeon Vega 8
Discrete graphics adapter model	Not available
On-board graphics adapter	Y
Graphics max dynamic frequency	1250 MHz
Discrete graphics adapter	N
LOGISTICS DATA
Harmonized System (HS) code	85423119
MEMORY
Memory channels	Dual-channel
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2933 MHz
Memory channels support	Dual-channel
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2933 MHz
PACKAGING DATA
Package type	Box
PROCESSOR
Processor model	3200G
Processor manufacturer	AMD
Processor model	3200G
Processor lithography	12 nm
Processor family	AMD Ryzen™ 3
Box	Yes
Processor socket	Socket AM4
Processor manufacturer	AMD
Package type	Box
Processor process	12 nm
Processor cores	4
Processor threads	4
Processor operating modes	64-bit
Component for	PC
Processor cache	4 MB
Processor family	AMD Ryzen 3
Thermal Design Power (TDP)	65 W
Box	Y
Processor socket	Socket AM4
Processor cache type	L3
Cooler included	Yes
Processor base frequency	3.6 GHz
Processor generation	AMD Ryzen 3000 Series
Processor number of cores	4
Processor number of threads	4
Processor operating modes	64-bit
Component for	PC
Processor cache	4 MB
Processor clock speed	3.6 GHz
Thermal Design Power (TDP)	65 W
Processor cache type	L3
Cooler included	Y
TECHNICAL DETAILS
Thermal Design Power (TDP)	65 W
Cache type	L3

Target Components

AMD Ryzen 3 3200G 4 Core AM4 Processor 3.8GHz up to 4.0GHz Boost, 6MB Cache, 65W, with Wraith Stealth Cooler, Radeon Vega 8 Graphics
