Target Components

PERFORMANCE

Processor
Intel® Core™ Ultra 5 235T, 14 cores (6 Performance + 8 Efficient), 14 threads, up to 5.0GHz

Processor Family
Intel® Core™ Ultra 5

Processor Generation
Intel® Core™ Ultra (Series 2)

Performance-Core Max Turbo Frequency
5.0 GHz

Efficient-Core Max Turbo Frequency
4.4 GHz

Performance-Core Base Frequency
2.2 GHz

Efficient-Core Base Frequency
1.6 GHz

Processor Cache
24 MB Intel® Smart Cache

Processor Base Power
35 W

Maximum Turbo Power
114 W

Neural Processing Unit (NPU)
Intel® AI Boost

NPU Features
Sparsity support
Windows Studio Effects support

AI Software Frameworks Supported by NPU
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN

Total Processor Performance
Up to 27 TOPS

NPU Performance
Up to 13 TOPS

GPU Performance
Up to 6 TOPS

Memory
16 GB DDR5-SDRAM

Memory Layout
1 x 16 GB

Memory Slots
2x SO-DIMM

Maximum Memory
64 GB

Memory Channels
Single-channel

Memory Data Transfer Rate
5600 MT/s

Non-ECC
Supported

Storage
512 GB SSD

Number of Storage Drives Installed
1

SSD Interface
PCI Express 4.0

SSD Form Factor
M.2

NVMe
Supported

Optical Drive
None

Graphics
Integrated Intel® Graphics

DESIGN

Product Type
Mini PC

Chassis Type
Micro PC

Placement Supported
Horizontal / Vertical

Product Colour
Black

Dimensions (W x D x H)
36 x 178 x 182 mm

Weight
1.16 kg

Cable Lock Slot
Supported

Cable Lock Slot Type
Kensington

Audio Chip
Realtek ALC3204

Audio System
High Definition Audio

SOFTWARE

Operating System
Windows 11 Pro, 64-bit

Trial Software
Activate Your Microsoft 365 for a 30-day trial

CONNECTIVITY

Ethernet
Intel WGI219LM, 10/100/1000 Mbit/s

Ethernet Cabling Technology
10/100/1000Base-T(X)

WLAN
Intel Wi-Fi 6E AX211

Wi-Fi Standard
Wi-Fi 6E (802.11ax)

Wi-Fi Standards Supported
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)

WLAN Controller Manufacturer
Intel

Antenna
2x2 Internal

Bluetooth
Supported

Front Ports
2x USB ports
1x Audio port

Rear Ports
3x USB 3.2 Gen 1 Type-A
1x USB 3.2 Gen 2 Type-C
2x USB 2.0
1x HDMI 2.1
1x DisplayPort 1.4a
1x Ethernet (RJ-45)
1x Combo headphone/microphone port
1x DC-in jack

USB Ports
3x USB 3.2 Gen 1 Type-A
1x USB 3.2 Gen 2 Type-C
2x USB 2.0

Video Outputs
1x HDMI 2.1
1x DisplayPort 1.4a

SECURITY & PRIVACY

Trusted Platform Module (TPM)
Supported, version 2.0

MANAGEABILITY

Intel® vPro™ Platform Eligibility
Supported

Motherboard Chipset
Intel® Q870

Market Positioning
Business

POWER

Power Supply
90 W

Power Supply Input Voltage
100–240 V

Power Supply Input Frequency
50 / 60 Hz

ENVIRONMENTAL CONDITIONS

Operating Temperature
10–35°C

Storage Temperature
-40–65°C

Operating Relative Humidity
20–80%

Storage Relative Humidity
5–95%

Operating Altitude
-15.2–3048 m

Non-Operating Altitude
-15.2–10668 m

Operating Vibration
0.26 G

Non-Operating Vibration
1.37 G

Operating Shock
40 G

Non-Operating Shock
105 G

ACCESSORIES

Mouse
Dell Optical Mouse MS116 – Black (included in selected markets)

Keyboard
Dell Wired Keyboard KB216 – UK (QWERTY), Black (included in selected markets)

CERTIFICATIONS

Sustainability Certificates
ENERGY STAR
EPEAT Climate+
EPEAT Gold

CARBON FOOTPRINT

Total Carbon Footprint
77.6 kg CO2e

Carbon Emissions – Manufacturing
41.516 kg CO2e

Carbon Emissions – Logistics
2.1728 kg CO2e

Carbon Emissions – Energy Usage
33.4456 kg CO2e

Carbon Emissions – End of Life
0.54 kg CO2e

PAIA Version
GaBi version 1, 2024
