| Case Style | Tiny |
| Processor | Intel Core i7 |
| Processor Cores | 20 |
| Storage | 512GB |
| Memory | 16GB |
| Graphics | On-chip |
| Operating Software | Windows 11 Pro |
| Case Style | Tiny |
| Processor | Intel Core i7 |
| Processor Cores | 20 |
| Storage | 512GB |
| Memory | 16GB |
| Graphics | On-chip |
| Operating Software | Windows 11 Pro |
| CERTIFICATES | |
|---|---|
| Certification | ENERGY STAR,TCO,EPEAT Silver,RoHS | DESIGN |
| Chassis type | mini PC |
| Cable lock slot | Yes |
| Product colour | Black |
| Volume | 1 L |
| Cable lock slot type | Kensington |
| Colour name | Black | DISPLAY |
| Display included | No | ENERGY MANAGEMENT |
| Power supply | 135 W |
| Power supply input voltage | 100 - 240 V |
| Power supply input frequency | 50/60 Hz | GRAPHICS |
| On-board graphics card model | Intel UHD Graphics 770 |
| Discrete graphics card model | Not available |
| On-board graphics card | Yes |
| Discrete graphics card | No |
| On-board graphics card family | Intel® UHD Graphics |
| On-board GPU manufacturer | Intel | MEMORY |
| Internal memory type | DDR5-SDRAM |
| Memory slots | 2x SO-DIMM |
| Maximum internal memory | 64 GB |
| Memory clock speed | 5600 MHz |
| Memory layout (slots x size) | 1 x 16 GB |
| Internal memory | 16 GB | NETWORKING |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Bluetooth version | 5.3 |
| Ethernet LAN | Yes |
| Antenna type | 2x2 |
| Bluetooth | Yes |
| Wi-Fi | Yes |
| Ethernet LAN data rates | 100,1000 Mbit/s |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| WLAN controller manufacturer | Intel | OPERATING SYSTEM/SOFTWARE |
| Operating system installed | Windows 11 Pro |
| Operating system architecture | 64-bit |
| Operating system language | English | OPERATIONAL CONDITIONS |
| Operating altitude | 0 - 3048 m |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating temperature (T-T) | 5 - 35 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Non-operating altitude | 0 - 12192 m | PACKAGING CONTENT |
| Contrast ratio (typical) | 10 - 90% |
| Display included | No |
| Mouse included | Yes |
| Keyboard included | Yes |
| Mouse connectivity | Wired |
| Keyboard connectivity | Wired | PERFORMANCE |
| Motherboard chipset | Intel Q670 |
| Audio system | High Definition Audio |
| Trusted Platform Module (TPM) | Yes |
| Number of speakers | 1 |
| Product type | Mini PC |
| Audio chip | Realtek ALC233VB | PORTS & INTERFACES |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| DisplayPorts quantity | 1 |
| Combo headphone/mic port | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| Thunderbolt 3 ports quantity | 0 | PROCESSOR |
| Processor model | i7-14700T |
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i7 |
| Processor cores | 20 |
| Processor threads | 28 |
| Processor boost frequency | 5.2 GHz |
| Processor cache | 33 MB |
| Processor cache type | Smart Cache |
| Efficient cores | 12 |
| Performance cores | 8 |
| Processor base power | 35 W |
| Maximum turbo power | 106 W |
| Efficient-core base frequency | 0.9 GHz |
| Performance-core base frequency | 1.3 GHz |
| Processor generation | Intel® Core™ i7 (14th gen) |
| Efficient-core Max Turbo Frequency | 3.7 GHz |
| Performance-core Max Turbo Frequency | 5 GHz | STORAGE |
| Optical drive type | No |
| Total storage capacity | 512 GB |
| Card reader integrated | No |
| SSD interface | PCI Express 4.0 |
| SSD capacity | 512 GB |
| Number of SSDs installed | 1 |
| Storage media | SSD |
| SSD form factor | M.2 |
| NVMe | Yes |
| Total SSDs capacity | 512 GB | WEIGHT & DIMENSIONS |
| Weight | 1.25 kg |
| Package weight | 2.85 kg |
| Height | 36.5 mm |
| Width | 179 mm |
| Depth | 182.9 mm |
| Package depth | 141 mm |
| Package height | 268 mm |
| Package width | 490 mm |
