COMPACT SIZE, COLOSSAL POWER
Boost your business performance with the Lenovo ThinkCentre Neo 30s Gen 5 SFF desktop, powered by Intel® Core™ processors. Perfect for a compact workspace, it delivers optimal performance, making demanding tasks feel effortless. Enjoy flexible storage, ample memory, and the power of optional Intel® Arc™ graphics — to keep pace with your ambitions.
COOL, EFFICIENT & SILENT
The ThinkCentre Neo 30s Gen 5 SFF desktop ensures optimal performance without overheating — thanks to its Intelligent Cooling Engine (ICE). Adaptive cooling modes facilitate cool, efficient computing even under heavy workloads. Plus, enjoy a quieter workspace with TUV Ultra Low Noise certification, allowing your team to stay focused without distractions.
BRIDGE DEVICES, BREAK BARRIERS
Stay connected and enjoy multidevice collaboration with this small-form-factor desktop. Whether exchanging medical files or sharing classroom notes — the Smart Connect app enables quick and secure cross-device interaction, seamlessly. Moreover, multitask like a pro with versatile ports, expansion slots, and optional Smart Cable for enhanced productivity.
BUILT-IN SAFEGUARDS YOU CAN TRUST
The ThinkCentre Neo 30s Gen 5 SFF desktop is fortified with ThinkShield's hardware and software security solutions. The firmware Trusted Platform Module (fTPM) provides data encryption while BIOS-level Smart USB protection prevents unauthorized access. Keep physical thefts at bay with Kensington Security Slot™, padlock loop, and an intrusion switch cable.
CREDIBILITY & COLLABORATION
Our goal is to provide smarter technology that builds a brighter, more sustainable future for our customers, communities, and the planet. That's why we pursue industry leading labels and certifications that demonstrate our commitment to sustainability in product design. Together, we can build a smarter future for all.
Tech Specs
Processor
Intel® Core™ i5-13420H, 8C (4P + 4E) / 12T, P-core 2.1 / 4.6GHz, E-core 1.5 / 3.4GHz, 12MB
Graphics
Integrated Intel® UHD Graphics
Chipset
Intel® SoC Platform
Memory
1x 8GB SO-DIMM DDR5-5200
Memory Slots
Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory
Up to 64GB DDR5-5200
Storage
256GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal
Max Storage Support
Up to two drives, 2x M.2 SSD
• M.2 SSD up to 1TB each
Card Reader
No card reader
Optical
None
Audio Chip
High Definition (HD) Audio, Realtek® ALC623-CG codec
Speakers
1Wx1
Power Supply
180W 85%
Keyboard
USB Calliope Keyboard, Black, English (UK)
Mouse
USB Calliope Mouse, Black
Expansion Slots
One PCIe® 4.0 x16, low-profile, length = 155mm, height = 70mm
One PCIe® 3.0 x1, low-profile, length = 155mm, height = 70mm
Three M.2 slots (one for WLAN, two for SSD)
Case Color
Chassis: Black, Bezel: Grey
Stand
None
Pen
Pen Not Supported
Form Factor
SFF (8.2L)
Dimensions (WxDxH)
92.5 x 291.7 x 339.5 mm (3.6 x 11.5 x 13.4 inches)
Weight
Around 4.63 kg (10.2 lbs)
WLAN + Bluetooth
Intel® Wi-Fi® 6 AX203, 802.11ax 2x2 + BT5.2
WWAN
Non-WWAN
Ethernet
Integrated 100/1000M
Front Ports
1x USB-C® (USB 5Gbps / USB 3.2 Gen 1), with 15W charging
2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x headphone / microphone combo jack (3.5mm)
1x microphone (3.5mm)
Rear Ports
2x USB-A (Hi-Speed USB / USB 2.0)
2x USB-A (USB 5Gbps / USB 3.2 Gen 1), one supports Smart Power On
1x HDMI® 2.1 TMDS
1x VGA
1x Ethernet (RJ-45)
1x line-out (3.5mm)
Optional Rear Ports (configured)
None
Monitor Cable
None
Security Chip
Firmware TPM 2.0 integrated in SoC
Physical Locks
Kensington® Security Slot™
Padlock Loop
Smart Cable Clip
None
Chassis Intrusion Switch
None
Additional Security
None
Base Warranty
1-year, Courier or Carry-in
Included Upgrade
1Y Onsite from 1Y Depot WHB (CPN)
Operating System
Windows® 11 Pro, English
Bundled Software
None
Bundled Accessories
Slim ODD Bracket Kit
Warranty:
1 year on-site warranty 0333 777 3991
DOA period 6 Days - This is from date of invoice. Customers to contact Lenovo to troubleshoot and they will advise process for return or repairs
|
CERTIFICATES
|
| Certification |
TCO |
DESIGN
|
| Chassis type |
SFF |
| Cable lock slot |
Yes |
| Product colour |
Black |
| Volume |
8.2 L |
| Cable lock slot type |
Kensington |
| Colour name |
Chassis: Black, Bezel: Grey |
DISPLAY
|
| Display included |
No |
ENERGY MANAGEMENT
|
| Power supply |
180 W |
| Power supply input voltage |
100 - 240 V |
| Power supply input frequency |
50/60 Hz |
GRAPHICS
|
| On-board graphics card model |
Intel® UHD Graphics |
| Discrete graphics card model |
Not available |
| On-board graphics card |
Yes |
| Discrete graphics card |
No |
| On-board graphics card family |
Intel® UHD Graphics |
| On-board GPU manufacturer |
Intel |
MEMORY
|
| Internal memory type |
DDR5-SDRAM |
| Memory slots |
2x SO-DIMM |
| Maximum internal memory |
64 GB |
| Memory clock speed |
5200 MHz |
| Memory layout (slots x size) |
1 x 8 GB |
| Internal memory |
8 GB |
NETWORKING
|
| Wi-Fi standards |
Wi-Fi 6 (802.11ax) |
| Bluetooth version |
5.2 |
| Ethernet LAN |
Yes |
| Antenna type |
2x2 |
| Bluetooth |
Yes |
| Wi-Fi |
Yes |
| Ethernet LAN data rates |
100,1000 Mbit/s |
| Top Wi-Fi standard |
Wi-Fi 6 (802.11ax) |
| WLAN controller model |
Intel Wi-Fi 6 AX203 |
| WLAN controller manufacturer |
Intel |
NEURAL PROCESSOR UNIT (NPU)
|
| Neural processor unit (NPU) |
No |
OPERATING SYSTEM/SOFTWARE
|
| Operating system installed |
Windows 11 Pro |
| Operating system language |
English |
PACKAGING CONTENT
|
| Display included |
No |
| Mouse included |
Yes |
| Keyboard included |
Yes |
| Mouse connectivity |
Wired |
| Keyboard connectivity |
Wired |
PERFORMANCE
|
| Motherboard chipset |
Intel SoC |
| Audio system |
High Definition Audio |
| Trusted Platform Module (TPM) |
Yes |
| Number of speakers |
1 |
| Product type |
PC |
| Audio chip |
Realtek ALC623-CG |
PORTS & INTERFACES
|
| Line-out |
Yes |
| USB 2.0 ports quantity |
2 |
| Ethernet LAN (RJ-45) ports |
1 |
| Microphone in |
Yes |
| VGA (D-Sub) ports quantity |
1 |
| HDMI ports quantity |
1 |
| HDMI version |
2.1 |
| Combo headphone/mic port |
Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
0 |
| Thunderbolt 3 ports quantity |
0 |
PROCESSOR
|
| Processor model |
i5-13420H |
| Processor manufacturer |
Intel |
| Processor family |
Intel® Core™ i5 |
| Processor cores |
8 |
| Processor threads |
12 |
| Processor boost frequency |
4.6 GHz |
| Processor cache |
12 MB |
| Processor cache type |
Smart Cache |
| Efficient cores |
4 |
| Performance cores |
4 |
| Processor base power |
45 W |
| Maximum turbo power |
95 W |
| Processor generation |
13th gen Intel® Core™ i5 |
| Efficient-core Max Turbo Frequency |
3.4 GHz |
| Performance-core Max Turbo Frequency |
4.6 GHz |
STORAGE
|
| Optical drive type |
No |
| Total storage capacity |
256 GB |
| Card reader integrated |
No |
| SSD interface |
PCI Express 4.0 |
| SSD capacity |
256 GB |
| Number of SSDs installed |
1 |
| Storage media |
SSD |
| SSD form factor |
M.2 |
| NVMe |
Yes |
| Total SSDs capacity |
256 GB |
TECHNICAL DETAILS
|
| Box contents |
Slim ODD Bracket Kit |
WEIGHT & DIMENSIONS
|
| Weight |
4.63 kg |
| Height |
339.5 mm |
| Width |
92.5 mm |
| Depth |
291.7 mm |
