PERFORMANCE
Processor
AMD Ryzen™ 5 PRO 7540U (6C / 12T, 3.2 / 4.9GHz, 6MB L2 / 16MB L3)
AI PC Category
Non-AI PC
NPU
None
Graphics
Integrated AMD Radeon™ 740M Graphics
Chipset
AMD SoC Platform
Memory
16GB Soldered LPDDR5X-6400
Memory Slots
Memory soldered to systemboard, no slots, dual-channel
Max Memory
16GB soldered memory, not upgradable
Storage
256GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0
Storage Slot
One M.2 2280 PCIe® 4.0 x4 slot
Max Storage Support
One drive, up to 2TB M.2 2280 SSD
Optical
None
Card Reader
No Card Reader
Audio Chip
High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers
Stereo speakers, 2W x2, Dolby Audio™
Microphone
2x, 360
Camera
FHD 1080p with Privacy Shutter
Battery
54.7Wh
Power Adapter
45W USB-C® (3-pin)
DESIGN
Display
13.3" WUXGA (1920 x 1200) IPS, 300 nits, Anti-glare, 100% sRGB, Touch
Touchscreen
On-cell, 10-point Multi-touch
Pen
Pen Not Supported
Keyboard
Backlit, English (UK)
Dimensions (W x D x H)
301.7 x 214.8 x 15.95 mm (11.88 x 8.46 x 0.63 inches)
Weight
Starting at 1.19 kg (2.63 lbs)
Case Color
Deep Black
Case Material
Carbon Fiber Hybrid (Top), Aluminium (Bottom)
SOFTWARE
Operating System
Windows® 11 Pro, English
Bundled Software
None
CONNECTIVITY
WLAN + Bluetooth
Qualcomm® Wi-Fi® 6E NFA725A, 802.11ax 2x2 + BT5.3
WWAN
WWAN Upgradable to 4G
SIM Card
No physical SIM card inbox
Ethernet
No Onboard Ethernet
NFC
No NFC
Standard Ports
1 x USB 3.2 Gen 1
1 x USB 3.2 Gen 1 (Always On)
2 x USB4® 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4a)
1 x HDMI® 2.1, up to 4K/60Hz
1 x Headphone / microphone combo jack (3.5mm)
Optional Ports (configured)
1 x Nano-SIM Card Slot
Docking
Various docking solutions supported via USB-C®
SECURITY & PRIVACY
ThinkShield
ThinkShield is a comprehensive security solution encompassing hardware, software, and supply chain components.
Security Chip
Discrete TPM 2.0 Enabled
Physical Locks
Kensington Nano Security Slot™, 2.5 x 6 mm
Smart Card Reader
No Smart Card Reader
Fingerprint Reader
No Fingerprint Reader
Other Security
Camera Privacy Shutter
Glance by Mirametrix®
MANAGEABILITY
System Management
DASH
SERVICE
Base Warranty
3-year, Courier or Carry-in with 1-year Battery
Included Upgrade
None
ACCESSORIES
Bundled Accessories
None
CERTIFICATIONS
Green Certifications
ENERGY STAR® 8.0
EPEAT Gold Registered
ErP Lot 6/26
RoHS Compliant
TCO Certified 9.0
Mil-Spec Test
MIL-STD-810H military test passed
Warranty:
3 Year Manufacturers Carry-In Warranty, Tel: 03337773991 Lenovo will first go through some fault finding/troubleshooting routines to see if they can solve the problem.
Within DOA Period: Lenovo will issue an authorisation number for return to the dealer/distributor.
Outside DOA Period: Lenovo will issue an RMA number and will handle the warranty direct with the end user (unless otherwise instructed).
This DOA period can vary so please verify this information with the manufacturer.
The item will have a base warranty when you first receive it. A base warranty is the manufacturing warranty to protect the product once it leaves the factory. Once the product is purchased and registered, the base warranty is deactivated and switches to the full consumer warranty providing the level of service that is included with the machine.
There are currently no data sheets available for this product.
