Target Components

PERFORMANCE

Processor
Intel Core™ Ultra 7 165H, 16C (6P + 8E + 2LPE) / 22T, Max Turbo up to 5.0GHz, 24MB Intel® Smart Cache

AI PC Category
AI-Ready Workstations

NPU
Integrated Intel® AI Boost, up to 11 TOPS

Graphics
NVIDIA® RTX 1000 Ada Generation 6GB GDDR6

Chipset
Intel® SoC Platform

Memory
1x 16GB SODIMM DDR5-5600 Non-ECC

Memory Slots
Two DDR5 SODIMM slots, dual-channel capable

Max Memory
Up to 96GB (2x 48GB DDR5 SODIMM)

Storage
512GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0

Storage Slot
Two M.2 2280 PCIe® 4.0 x4 slots

Max Storage Support
Up to two drives, 2x M.2 SSD; M.2 2280 SSD up to 4TB, 2TB each

RAID Preset
None

Card Reader
SD Express 7.0 Card Reader

Audio Chip
High Definition (HD) Audio, Realtek® ALC3287 codec

Speakers
Stereo speakers, 2W x2, Dolby Audio™ Premium

Microphone
2x, Array

Camera
5.0MP + IR with Privacy Shutter and Human Presence Detection

Battery
90Wh

Power Adapter
170W Slim Tip (3-pin)

DESIGN

Display
16" WUXGA (1920x1200) IPS 300nits Anti-glare, 45% NTSC

Touchscreen
None

Color Calibration
No Color Calibration

Pen
Pen Not Supported

Keyboard
Backlit, English (UK)

Dimensions (WxDxH)
365 x 262 x 24.66 mm (14.37 x 10.32 x 0.97 inches)

Weight
Starting at 2.22 kg (4.90 lbs)

Case Color
Black

Case Material
PC-ABS (Top), PC-ABS (Bottom)

SOFTWARE

Operating System
Windows® 11 Pro, English

Bundled Software
Intel® Connectivity Performance Suite

CONNECTIVITY

WLAN + Bluetooth
Intel® Wi-Fi® 6E AX211, 802.11ax 2x2 + BT5.3, vPro®

WWAN
WWAN Not Supported

SIM Card
No SIM card included (nano-SIM card slot available)

Ethernet
100/1000M (RJ-45)

NFC
No NFC

Standard Ports
1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with DisplayPort™ 2.1
1x HDMI® 2.1, up to 8K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (GbE RJ-45)
1x SD Express 7.0 card reader
1x Kensington Nano Security Slot™

Optional Ports (Configured)
None

Docking
Various docking solutions supported via Thunderbolt™ / USB-C®. For more compatible docking solutions, please visit Docking for ThinkPad® P16v Gen 2

SECURITY & PRIVACY

Security Chip
Discrete TPM 2.0 Enabled

Physical Locks
Kensington Nano Security Slot™, 2.5 x 6 mm

Smart Card Reader
No Smart Card Reader

Fingerprint Reader
Touch Style, Match-on-Chip, Integrated in Power Button

Other Security
Camera privacy shutter (camera models)
Ultrasonic Human Presence Detection for IR camera
IR camera for Windows® Hello (facial recognition)

MANAGEABILITY

System Management
Intel® vPro® Enterprise

SERVICE

Base Warranty
3-year, Courier or Carry-in with 1-year Battery

Included Upgrade
None

ACCESSORIES

Bundled Accessories
None

CERTIFICATIONS

ISV Certifications
Please visit ISV certifications for Lenovo® Workstations

Green Certifications
ENERGY STAR® 9.0
EPEAT Gold Registered
RoHS compliant
TCO Certified, generation 9

Mil-Spec Test
MIL-STD-810H military test passed
