PERFORMANCE
Processor
Intel® Core™ Ultra 5 135U, 12C (2P + 8E + 2LPE) / 14T, Max Turbo up to 4.4GHz, 12MB Intel® Smart Cache
AI PC Category
AI PC
NPU
Integrated Intel® AI Boost, up to 11 TOPS
Graphics
Integrated Intel® Graphics
Chipset
Intel® SoC Platform
Memory
2x 8GB SODIMM DDR5-5600
Memory Slots
Two DDR5 SODIMM slots, dual-channel capable
Max Memory
Up to 64GB DDR5-5600
Storage
512GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0
Storage Slot
One M.2 2280 PCIe® 4.0 x4 slot
Max Storage Support
One drive, up to 2TB M.2 2280 SSD
Optical
None
Card Reader
No Card Reader
Audio Chip
High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers
Stereo speakers, 2W x2, Dolby Audio™
Microphone
2x, 360°
Camera
5.0MP + IR Discrete with Privacy Shutter
Battery
52.5Wh
Power Adapter
65W USB-C® (3-pin)
DESIGN
Display
14" WUXGA (1920x1200) IPS 500nits Anti-glare, 100% sRGB, 60Hz, ThinkPad® Privacy Guard, Touch
Touchscreen
On-cell, 10-point Multi-touch
Screen-to-Body Ratio
85.73%
Pen
Pen Not Supported
Keyboard
Backlit, English (UK)
Dimensions (WxDxH)
315.9 x 223.7 x 17.7 mm (12.44 x 8.81 x 0.7 inches)
Weight
Starting at 1.38 kg (3.05 lbs)
Case Color
Black
Case Material
PC + 20% CF (Top), PC + 20% CF (Bottom)
SOFTWARE
Operating System
Windows® 11 Pro, English
Bundled Software
Intel® Connectivity Performance Suite
CONNECTIVITY
WLAN + Bluetooth
Intel® Wi-Fi® 6E AX211, 802.11ax 2x2 + BT5.3, vPro®
WWAN
WWAN Upgradable to 4G
SIM Card
No physical SIM card inbox
Ethernet
100/1000M (RJ-45)
NFC
No NFC
Standard Ports
1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 3.0 and DisplayPort™ 2.1
1x HDMI® 2.1, up to 4K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
Optional Ports (configured)
1x Nano-SIM Card Slot
Docking
Various docking solutions supported via Thunderbolt™ / USB-C®
SECURITY & PRIVACY
ThinkShield
ThinkShield is a comprehensive security solution that encompasses hardware, software and supply chain components.
Security Chip
Discrete TPM 2.0 Enabled
Physical Locks
Kensington Nano Security Slot™, 2.5 x 6 mm
Smart Card Reader
No Smart Card Reader
Fingerprint Reader
Touch Style, Match-on-Chip, Integrated in Power Button
Other Security
Camera privacy shutter (camera models)
Ultrasonic Human Presence Detection
IR camera for Windows® Hello (facial recognition)
Privacy Guard with Privacy Alert (models with ThinkPad® Privacy Guard display)
MANAGEABILITY
System Management
Intel® vPro® Enterprise
SERVICE
Base Warranty
3-year, Courier or Carry-in with 1-year Battery
Included Upgrade
None
ACCESSORIES
Bundled Accessories
None
CERTIFICATIONS
Green Certifications
ENERGY STAR® 9.0
EPEAT Gold Registered
ErP Lot 6/26
RoHS compliant
TCO Certified, generation 10
Mil-Spec Test
MIL-STD-810H military test passed
Warranty:
3 Year Manufacturers Carry-In Warranty, Tel: 03337773991 Lenovo will first go through some fault finding/troubleshooting routines to see if they can solve the problem.
Within DOA Period: Lenovo will issue an authorisation number for return to the dealer/distributor.
Outside DOA Period: Lenovo will issue an RMA number and will handle the warranty direct with the end user (unless otherwise instructed).
This DOA period can vary so please verify this information with the manufacturer.
The item will have a base warranty when you first receive it. A base warranty is the manufacturing warranty to protect the product once it leaves the factory. Once the product is purchased and registered, the base warranty is deactivated and switches to the full consumer warranty providing the level of service that is included with the machine.
There are currently no data sheets available for this product.
