PERFORMANCE
Processor
Intel® Core™ Ultra 5 325, 8C (4P + 4LPE) / 8T, Max Turbo up to 4.5GHz, 12MB Intel® Smart Cache
AI PC Category
Copilot+ PC
NPU
Up to 47 TOPS
Graphics
Integrated Intel® Graphics
Chipset
Intel® SoC Platform
Memory
1x 16GB SODIMM DDR5-5600
Memory Slots
Two DDR5 SODIMM slots, dual-channel capable
Max Memory
Up to 64GB DDR5-5600
Storage
512GB SSD M.2 2242 PCIe® 4.0 x4 NVMe®
Storage Slot
Two M.2 slots
One M.2 2242 PCIe® 4.0 x4 slot
One M.2 2280 PCIe® 4.0 x4 slot
Max Storage Support
Up to two drives, 2x M.2 SSD
M.2 2242 SSD up to 2TB
M.2 2280 SSD up to 2TB
Card Reader
SD Card Reader
Audio Chip
High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers
Stereo speakers, 2W x2, Dolby Audio™
Microphone
2x, Array
Camera
FHD 1080p + IR Hybrid with Privacy Shutter
Battery
48Wh
Power Adapter
65W USB-C® (3-pin)
Special Features
Modern Standby
DESIGN
Display
16" WUXGA (1920 x 1200) IPS, 400 nits, Anti-glare, 45% NTSC, 60Hz
Touchscreen
None
Screen-to-Body Ratio
90%
Color Calibration
No Color Calibration
Pen
Pen Not Supported
Keyboard
Backlit, English (UK)
Touchpad
Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)
Dimensions (W x D x H)
356 x 253.5 x 17.5 mm (14.01 x 9.98 x 0.69 inches)
Weight
Starting at 1.7 kg (3.75 lbs)
Case Colour
Arctic Grey
Case Material
Aluminium (Top), PC-ABS (Bottom)
Surface Treatment
Anodizing Sandblasting (Top), Texture (Bottom)
SOFTWARE
Operating System
Windows® 11 Pro, English (US) / English (UK)
Bundled Software
Office Trial
CONNECTIVITY
WLAN + Bluetooth
Wi-Fi® 7, 802.11be 2x2 + Bluetooth® 5.4
WWAN
WWAN Not Supported
Ethernet
100/1000M (RJ-45)
Standard Ports
1x USB-A (USB 5Gbps), Always On
1x USB-A (USB 5Gbps)
2x Thunderbolt™ 4, with USB PD 45–65W and DisplayPort™ 2.1
1x HDMI® 2.1, up to 4K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
1x SD card reader
Docking
Various docking solutions supported via Thunderbolt™ / USB-C®.
SECURITY & PRIVACY
Security Chip
Discrete TPM 2.0 Enabled
Physical Locks
Kensington Nano Security Slot™, 2.5 x 6 mm
Fingerprint Reader
Touch Style, Match-on-Chip, Integrated in Power Button
Other Security
Camera privacy shutter
IR camera for Windows® Hello (facial recognition)
MANAGEABILITY
System Management
Non-vPro®
SERVICE
Base Warranty
1-year, Courier or Carry-in
Included Upgrade
None
ACCESSORIES
Bundled Accessories
None
CERTIFICATIONS
Green Certifications
ENERGY STAR® 9.0
EPEAT 1.0 Gold Registered
ErP Lot 6/26
RoHS compliant
TCO Certified, generation 10
Mil-Spec Test
MIL-STD-810H military test passed
Other Certifications
TUV Rheinland® Low Blue Light (Software Solution)
Warranty:
1 Year Manufacturers Carry-In Warranty, Tel: 03337773991 Lenovo will first go through some fault finding/troubleshooting routines to see if they can solve the problem.
Within DOA Period: Lenovo will issue an authorisation number for return to the dealer/distributor.
Outside DOA Period: Lenovo will issue an RMA number and will handle the warranty direct with the end user (unless otherwise instructed).
This DOA period can vary so please verify this information with the manufacturer.
The item will have a base warranty when you first receive it. A base warranty is the manufacturing warranty to protect the product once it leaves the factory. Once the product is purchased and registered, the base warranty is deactivated and switches to the full consumer warranty providing the level of service that is included with the machine.
|
AUDIO
|
| Audio system |
Dolby Audio |
| Built-in microphone |
Yes |
| Speaker power |
2 W |
| Number of built-in speakers |
2 |
| Number of microphones |
2 |
| Audio chip |
Realtek ALC3287 |
BATTERY
|
| Battery capacity (Watt-hours) |
48 Wh |
CAMERA
|
| Front camera |
Yes |
| Front camera resolution |
1920 x 1080 pixels |
| Privacy camera |
Yes |
| Privacy type |
Privacy shutter |
| Front camera HD type |
Full HD |
| Infrared (IR) camera |
Yes |
CERTIFICATES
|
| Certification |
ENERGY STAR,TCO,TCO10,EPEAT Gold,RoHS,ErP |
DESIGN
|
| Form factor |
Clamshell |
| Product colour |
Grey |
| Housing material |
Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC) |
| Product type |
Laptop |
| Colour name |
Arctic Grey |
| Stylus pen support |
No |
| Display back cover material |
Aluminium |
DISPLAY
|
| Display diagonal |
40.6 cm (16") |
| Display brightness |
400 cd/m² |
| Display resolution |
1920 x 1200 pixels |
| Touchscreen |
No |
| LED backlight |
Yes |
| Maximum refresh rate |
60 Hz |
| Anti-glare screen |
Yes |
| Native aspect ratio |
16:10 |
| HD type |
WUXGA |
| Colour gamut |
45% |
| Panel type |
IPS |
| RGB colour space |
NTSC |
ENERGY MANAGEMENT
|
| AC adapter power |
65 W |
| USB Power Delivery (USB PD) |
Yes |
| USB Type-C charging port |
Yes |
| USB Type-C required charging power (min) |
45 W |
| USB Type-C required charging power (max) |
65 W |
GRAPHICS
|
| On-board graphics card model |
Intel® Graphics |
| Discrete graphics card model |
Not available |
| On-board graphics card |
Yes |
| Discrete graphics card |
No |
| On-board graphics card family |
Intel® Graphics |
| On-board GPU manufacturer |
Intel |
KEYBOARD
|
| Pointing device |
Touchpad |
| Numeric keypad |
Yes |
| Built-in touchpad |
Yes |
| Keyboard language |
UK English |
| Keyboard backlit |
Yes |
| Copilot key |
Yes |
MEMORY
|
| Internal memory type |
DDR5-SDRAM |
| Memory slots |
2x SO-DIMM |
| Maximum internal memory |
64 GB |
| Memory clock speed |
5600 MHz |
| Memory form factor |
SO-DIMM |
| Memory channels |
Dual-channel |
| Memory layout (slots x size) |
1 x 16 GB |
| Internal memory |
16 GB |
NETWORKING
|
| Wi-Fi standards |
Wi-Fi 7 (802.11be) |
| Bluetooth version |
5.4 |
| Ethernet LAN |
Yes |
| Antenna type |
2x2 |
| Bluetooth |
Yes |
| Ethernet LAN data rates |
100,1000 Mbit/s |
| WWAN |
Not installed |
| Mobile network connection |
No |
| Top Wi-Fi standard |
Wi-Fi 7 (802.11be) |
NEURAL PROCESSOR UNIT (NPU)
|
| NPU performance up to |
47 TOPs |
| Copilot+ PC |
Yes |
OPERATING SYSTEM/SOFTWARE
|
| Operating system installed |
Windows 11 Pro |
| Trial software |
Office |
| Operating system language |
US English, ENG-UK |
| Microsoft Copilot |
Yes |
| Copilot+ PC |
Yes |
OTHER FEATURES
|
| AC adapter included |
Yes |
PACKAGING CONTENT
|
| AC adapter included |
Yes |
| Stylus pen |
No |
PERFORMANCE
|
| Motherboard chipset |
Intel SoC |
PORTS & INTERFACES
|
| USB 2.0 ports quantity |
0 |
| Ethernet LAN (RJ-45) ports |
1 |
| HDMI ports quantity |
1 |
| HDMI version |
2.1 |
| Combo headphone/mic port |
Yes |
| USB Sleep-and-Charge |
Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| USB Power Delivery |
Yes |
| Thunderbolt 4 ports quantity |
2 |
| Intel® Thunderbolt 4 |
Yes |
PROCESSOR
|
| Processor model |
325 |
| Motherboard chipset |
Intel SoC |
| Processor manufacturer |
Intel |
| Processor family |
Intel Core Ultra 5 |
| Processor cores |
8 |
| Processor threads |
8 |
| Processor cache |
12 MB |
| Processor cache type |
Smart Cache |
PROCESSOR SPECIAL FEATURES
|
| Intel® Smart Cache |
Yes |
SECURITY
|
| Cable lock slot |
Yes |
| Trusted Platform Module (TPM) |
Yes |
| Fingerprint reader |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Cable lock slot type |
Kensington, Nano |
| Windows Hello |
Yes |
STORAGE
|
| Compatible memory cards |
SD |
| Optical drive type |
No |
| Total storage capacity |
512 GB |
| Card reader integrated |
Yes |
| SSD interface |
PCI Express 4.0 |
| SSD capacity |
512 GB |
| Number of SSDs installed |
1 |
| Storage media |
SSD |
| SSD form factor |
M.2 |
| NVMe |
Yes |
| Total SSDs capacity |
512 GB |
| M.2 SSD size |
2242 (22 x 42 mm) |
WEIGHT & DIMENSIONS
|
| Weight |
1.7 kg |
| Height |
17.5 mm |
| Width |
356 mm |
| Depth |
253.5 mm |
