PERFORMANCE

Processor
AMD Ryzen™ 5 7520U (4C / 8T, 2.8 / 4.3GHz, 2MB L2 / 4MB L3)

Graphics
Integrated AMD Radeon™ 610M Graphics

Chipset
AMD SoC Platform

Memory
8GB Soldered LPDDR5-5500

Memory Slots
Memory soldered to systemboard, no slots, dual-channel

Max Memory
8GB soldered memory, not upgradable

Storage
256GB SSD M.2 2242 PCIe® 4.0x4 NVMe®

Storage Slot
One M.2 2242 PCIe® 3.0 x2 slot

Max Storage Support
One drive, up to 1TB M.2 2242 SSD

Optical
None

Card Reader
No Card Reader

Audio Chip
High Definition (HD) Audio, Realtek® ALC3287 codec

Speakers
Stereo speakers, 1.5W x2, Dolby Audio™

Microphone
2x, Array

Camera
HD 720p with Privacy Shutter

Battery
38Wh

Power Adapter
65W Round Tip (3-pin)

DESIGN

Display
14" FHD (1920x1080) TN 250nits Anti-glare

Touchscreen
None

Screen-to-Body Ratio
87%

Pen
Pen Not Supported

Keyboard
Non-backlit, English (UK)

Touchpad
Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 62 x 104 mm (2.44 x 4.09 inches)

Dimensions (WxDxH)
324.2 x 215.2 x 19.9 mm (12.76 x 8.47 x 0.78 inches)

Weight
Less than 1.37 kg (3.02 lbs)

Case Color
Business Black

Case Material
PC-ABS (Top), PC-ABS (Bottom)

Surface Treatment
Texture

SOFTWARE

Operating System
Windows® 11 Pro, English

Bundled Software
Office Trial

CONNECTIVITY

WLAN + Bluetooth
Wi-Fi® 6, 802.11ax 2x2 + BT5.3

WWAN
WWAN Not Supported

Ethernet
100/1000M (RJ-45)

Standard Ports
2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x USB-C® (USB 5Gbps / USB 3.2 Gen 1), with USB PD 45-65W and DisplayPort™ 1.2
1x HDMI® 1.4b
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
1x Round tip power connector

Docking
Various docking solutions supported via USB-C®. For more compatible docking solutions, please visit Docking for Lenovo® V14 G4 AMN

SECURITY & PRIVACY

Security Chip
Firmware TPM 2.0 Enabled

Physical Locks
Kensington Nano Security Slot™, 2.5 x 6 mm

Fingerprint Reader
No Fingerprint Reader

Other Security
Camera privacy shutter

SERVICE

Base Warranty
1-year, Courier or Carry-in

Included Upgrade
None

ACCESSORIES

Bundled Accessories
None

CERTIFICATIONS

Green Certifications
ENERGY STAR® 9.0
EPEAT 1.0 Silver Registered
ErP Lot 3
FSC certified package
RoHS compliant

Mil-Spec Test
MIL-STD-810H military test passed

Other Certifications
TUV Rheinland® Low Blue Light (Software Solution)
