PERFORMANCE
Processor
AMD Ryzen™ 7 170 (8C / 16T, 3.2 / 4.75GHz, 4MB L2 / 16MB L3)
Graphics
Integrated AMD Radeon™ 680M Graphics
Chipset
AMD SoC Platform
Memory
16GB DDR5-4800 (1 x 16GB SODIMM)
Memory Slots
Two DDR5 SODIMM slots, dual-channel capable
Max Memory
Up to 32GB DDR5-4800
Storage
512GB SSD M.2 2242 PCIe® 4.0x4 NVMe®
Storage Slot
One M.2 2280 PCIe® 4.0 x4 slot
Max Storage Support
One drive, up to 1TB M.2 2242 SSD
Optical
None
Card Reader
No Card Reader
Audio Chip
High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers
Stereo speakers, 2W x2
Microphone
2x Array Microphones
Camera
HD 720p Camera with Privacy Shutter
Battery
47Wh
Power Adapter
65W Round Tip (3-pin)
DESIGN
Display
14" FHD (1920 x 1080) TN, 300 nits, Anti-glare, 45% NTSC, 60Hz
Touchscreen
None
Screen-to-Body Ratio
87%
Pen
Pen Not Supported
Keyboard
Non-backlit, English (UK)
Touchpad
Buttonless Mylar® Surface Multi-touch Touchpad, supports Precision TouchPad (PTP), 70 x 105 mm (2.76 x 4.13 inches)
Dimensions (W x D x H)
324.2 x 215.2 x 19.9 mm (12.76 x 8.47 x 0.78 inches)
Weight
Starting at 1.37 kg (3.02 lbs)
Case Color
Business Black
Case Material
PC-ABS (Top), PC-ABS (Bottom)
Surface Treatment
Texture
SOFTWARE
Operating System
Windows® 11 Pro, English (US) / English (UK)
Bundled Software
Office Trial
CONNECTIVITY
WLAN + Bluetooth
Wi-Fi® 6 (802.11ax 2x2) + Bluetooth® 5.2
WWAN
WWAN Not Supported
Ethernet
100/1000M (RJ-45)
Standard Ports
2 x USB-A (USB 5Gbps)
1 x USB-C® (USB 10Gbps) with USB Power Delivery 45-65W and DisplayPort™ 1.2
1 x HDMI® 1.4b
1 x Headphone / Microphone Combo Jack (3.5mm)
1 x Ethernet (RJ-45)
1 x Round Tip Power Connector
Docking
Various docking solutions supported via USB-C®
SECURITY & PRIVACY
Security Chip
Discrete TPM 2.0 Enabled
Physical Locks
Kensington Nano Security Slot™ (2.5 x 6 mm)
Fingerprint Reader
No Fingerprint Reader
Other Security
Camera Privacy Shutter
SERVICE
Base Warranty
1-year, Courier or Carry-in
Included Upgrade
None
ACCESSORIES
Bundled Accessories
None
CERTIFICATIONS
Green Certifications
ENERGY STAR® 9.0
ErP Lot 6/26
RoHS Compliant
Mil-Spec Test
MIL-STD-810H Military Test Passed
Other Certifications
TÜV Rheinland® Low Blue Light (Software Solution)
Warranty:
1 Year Manufacturers Carry-In Warranty, Tel: 03337773991 Lenovo will first go through some fault finding/troubleshooting routines to see if they can solve the problem.
Within DOA Period: Lenovo will issue an authorisation number for return to the dealer/distributor.
Outside DOA Period: Lenovo will issue an RMA number and will handle the warranty direct with the end user (unless otherwise instructed).
This DOA period can vary so please verify this information with the manufacturer.
The item will have a base warranty when you first receive it. A base warranty is the manufacturing warranty to protect the product once it leaves the factory. Once the product is purchased and registered, the base warranty is deactivated and switches to the full consumer warranty providing the level of service that is included with the machine.
