| AUDIO | |
|---|---|
| Number of built-in speakers | 2 |
| RMS rated power | 30 W |
| Audio output channels | 2.0 channels |
| Built-in speaker(s) | Yes |
| Enhanced Audio Return Channel (eARC) | Yes | COMPUTER SYSTEM |
| Operating system installed | Android |
| Operating system version | 14 |
| Built-in processor | Yes |
| Internal storage capacity | 16 GB |
| On-board graphics card model | ARM Mali-G52 |
| Processor frequency | 2.2 GHz |
| Internal memory | 4 GB |
| Computer system | Yes | DESIGN |
| Product colour | Black |
| Placement supported | Indoor |
| Panel mounting interface | 500 x 400 mm |
| Product design | Digital signage flat panel |
| Mounting type | Wall |
| VESA mounting | Yes |
| Screen shape | Flat |
| Orientation | Landscape | DISPLAY |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display diagonal | 2.16 m (85") |
| Contrast ratio (typical) | 20 - 80% |
| Display brightness | 400 cd/m² |
| Response time | 6.5 ms |
| Display resolution | 3840 x 2160 pixels |
| Touchscreen | No |
| LED backlighting type | Direct-LED |
| Display technology | LED |
| Native aspect ratio | 16:9 |
| HD type | 4K Ultra HD |
| Rated lifetime | 50000 h |
| Active display area (W x H) | 1872 x 1053 mm |
| Display number of colours | 1.07 billion colours |
| Haze rate | 2% |
| Native refresh rate | 60 Hz | ENERGY MANAGEMENT |
| Power consumption (typical) | 138 W |
| Power consumption (standby) | 0.3 W |
| Energy efficiency scale | A to G |
| Energy efficiency class (SDR) | F |
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 138 kWh | NETWORK |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| Ethernet LAN | Yes |
| Wi-Fi | Yes | OPERATIONAL CONDITIONS |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 20 - 80% | OTHER FEATURES |
| Power supply type | Internal |
| Bluetooth version | 5.0 |
| Bluetooth | Yes |
| Built-in subwoofer | Yes | PACKAGING DATA |
| Package weight | 41.1 kg |
| Package depth | 192 mm |
| Package height | 1250 mm |
| Package width | 2030 mm | PERFORMANCE |
| Purpose | Universal |
| HDCP | Yes |
| HDCP version | 2.2 |
| Operating hours (hours/days) | 24/7 |
| Over the Air Updates (OTA) | Yes | PORTS & INTERFACES |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| Ethernet LAN | Yes |
| USB connector type | USB Type-A |
| Ethernet LAN (RJ-45) ports | 1 |
| DVI port | No |
| Wi-Fi | Yes |
| Audio (L/R) out | 1 |
| HDMI ports quantity | 3 |
| RS-232 interface | Yes |
| HDMI version | 2.1 |
| Audio Return Channel (ARC) | Yes |
| USB version | 2.0 |
| USB ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB port | Yes | WEIGHT & DIMENSIONS |
| Display depth | 91 mm |
| Display height | 1081 mm |
| Display weight | 28.8 kg |
| Display width | 1890 mm |
