| Screen Size (in) | 15.6 |
| Max Resolution | 1366x768 |
| Response Time | 12ms |
| Display Port | No |
| Height Adjustable | No |
| Curved Screen | No |
| Screen Size (in) | 15.6 |
| Max Resolution | 1366x768 |
| Response Time | 12ms |
| Display Port | No |
| Height Adjustable | No |
| Curved Screen | No |
| DESIGN | |
|---|---|
| Product colour | Black |
| Glass thickness | 0.83 mm |
| Surface hardness | 7H | DISPLAY |
| Pixel pitch | 0.252 x 0.252 mm |
| Contrast ratio (typical) | 500:1 |
| Horizontal scan range | 30 - 61 kHz |
| Viewing angle, horizontal | 110° |
| Viewing angle, vertical | 85° |
| Aspect ratio | 16:9 |
| Vertical scan range | 56 - 75 Hz |
| Display diagonal | 39.6 cm (15.6") |
| Display brightness | 220 cd/m² |
| Response time | 12 ms |
| Display resolution | 1366 x 768 pixels |
| Display diagonal (metric) | 39.62 cm |
| Contrast ratio (dynamic) | 40000000:1 |
| High frequency rate | 60 Hz |
| LED backlight | Yes |
| Display technology | LED |
| Native aspect ratio | 16:9 |
| HD type | HD |
| Panel type | TFT |
| Screen shape | Flat |
| Display number of colours | 262144 colours | ENERGY MANAGEMENT |
| Power consumption (typical) | 10 W |
| Power supply type | AC |
| AC adapter output voltage | 12 V |
| Power consumption (off) | 0.3 W |
| Power consumption (standby) | 0.5 W |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100-240 V |
| Energy efficiency scale | A to G |
| Energy efficiency class (SDR) | B |
| Energy consumption (SDR) per 1000 hours | 6 kWh | ERGONOMICS |
| Cable lock slot | Yes |
| LED indicators | Yes |
| Wall mountable | Yes |
| Tilt angle range | 15 - 50° |
| Panel mounting interface | 75 x 75 mm |
| Cable lock slot type | Kensington |
| VESA mounting | Yes |
| Tiltable | Y | OPERATIONAL CONDITIONS |
| Operating relative humidity (H-H) | 20 - 85% |
| Operating temperature (T-T) | 5 - 35 °C | PACKAGING CONTENT |
| AC adapter included | Yes |
| Cables included | AC, HDMI |
| Quick start guide | Yes |
| Stand included | Yes | PACKAGING DATA |
| Package weight | 2.36 kg |
| Package depth | 86 mm |
| Package height | 390 mm |
| Package width | 453 mm | PERFORMANCE |
| Built-in microphone | No |
| RMS rated power | 2 W |
| Built-in speaker(s) | Yes |
| Number of OSD languages | 15 |
| Touch technology | Multi-touch |
| Touchscreen technology | Projected capacitive system |
| Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 8 |
| Built-in camera | No |
| Touchscreen type | Tabletop |
| Number of speakers | 2 |
| Number of simultaneous touchpoints | 10 | PORTS & INTERFACES |
| Audio input | Yes |
| Headphone outputs | 1 |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI | Yes |
| DisplayPorts quantity | 0 |
| Built-in USB hub | No | SUSTAINABILITY |
| Sustainability certificates | ENERGY STAR | TECHNICAL DETAILS |
| Glass protection | Yes |
| Harmonized System (HS) code | 85285210 | WEIGHT & DIMENSIONS |
| Weight (without stand) | 1.32 kg |
| Height (without stand) | 390 mm |
| Width (without stand) | 379.2 mm |
| Depth (without stand) | 86 mm |
