| Chipset Manufacturer | Nvidia |
| Chipset Series | GeForce RTX |
| Chipset | RTX5060Ti |
| Form Factor | 2 x ATX |
| Memory | 8GB |
| Fans | 2 |
| RGB | No |
| Chipset Manufacturer | Nvidia |
| Chipset Series | GeForce RTX |
| Chipset | RTX5060Ti |
| Form Factor | 2 x ATX |
| Memory | 8GB |
| Fans | 2 |
| RGB | No |
Gigabyte 3-Year Return-To-Base Warranty
Warranty Length: 3 years
Warranty Type:Return-To-Base
Warranty Coverage: Gigabyte's 3-year warranty includes a 30-day DOA period covering manufacturing defects and faults. If a product becomes faulty within the first 30 days of purchase, it can be returned to Target under the 30-Day DOA agreement, at which point we will replace it where possible, or offer account credit. If it becomes faulty after the first 30 days the product will be repaired or replaced with a graded unit. Account credit will be unavailable outside of the 30-day DOA agreement. The end user will need to return it to the reseller they purchased it from originally. If the unit is found faulty within the first 30 days of purchase, it can be returned to the reseller to claim under DOA with Target - a proof of end-user purchase WILL be required.
Warranty Instructions: RESELLERS - please raise a Target RMA.
END USERS - in the first instance, please return it to the reseller you originally purchased it. Target is unable to deal with end-user warranty issues. In the event an end-user is unable to contact the reseller, they must contact Gigabyte directly via Gigabyte Returns.
Warranty Information: https://www.gigabyte.com/uk/Support/Consumer/Warranty
Warranty Contact: Gigabyte Returns
| DESIGN | |
|---|---|
| Form factor | Full-Height/Half-Length (FH/HL) |
| Number of slots | 2 |
| Product colour | White |
| Number of fans | 2 fan(s) |
| Cooling type | Active |
| Cooling technology | GIGABYTE WINDFORCE 2X | ENERGY MANAGEMENT |
| Minimum system power supply | 650 W |
| Supplementary power connectors | 1x 8-pin |
| Thermal Design Power (TDP) | 135 W | LOGISTICS DATA |
| Products per shipping (inner) case | 1 pc(s) | MEMORY |
| Graphics card memory type | GDDR7 |
| Data transfer rate | 28 Gbit/s |
| Memory bus | 128 bit |
| Memory clock speed | 28000 MHz |
| Discrete graphics card memory | 8 GB | PACKAGING DATA |
| Package weight | 960 g |
| Package depth | 330 mm |
| Package height | 57 mm |
| Package width | 235 mm |
| Package type | Box | PERFORMANCE |
| TV tuner integrated | No |
| DirectX version | 12.0 |
| OpenGL version | 4.6 |
| Dual Link DVI | No |
| NVIDIA G-SYNC | Yes |
| Warranty period | 3 year(s) | PORTS & INTERFACES |
| Interface type | PCI Express x8 5.0 |
| DVI-I ports quantity | 0 |
| DVI-D ports quantity | 0 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1b |
| DisplayPorts quantity | 3 |
| Mini HDMI ports quantity | 0 |
| Mini DisplayPorts quantity | 0 |
| DisplayPort version | 2.1b |
| Thunderbolt 3 ports quantity | 0 | PROCESSOR |
| Processor frequency | 2617 MHz |
| Graphics processor | GeForce RTX 5060 Ti |
| Maximum resolution | 7680 x 4320 pixels |
| Parallel processing technology support | Not supported |
| Maximum displays per videocard | 4 |
| CUDA | Yes |
| CUDA cores | 4608 |
| Graphics processor family | NVIDIA | TECHNICAL DETAILS |
| Warranty period | 3 year(s) | WEIGHT & DIMENSIONS |
| Weight | 600 g |
| Height | 122 mm |
| Depth | 40 mm |
| Length | 215 mm |
