| Chipset Manufacturer | AMD |
| Chipset Series | RX |
| Chipset | RX 9060 XT |
| Form Factor | ATX |
| Memory | 16GB |
| Fans | 3 |
| RGB | Yes |
Gigabyte 3-Year Return-To-Base Warranty
Warranty Length: 3 years
Warranty Type:Return-To-Base
Warranty Coverage: Gigabyte's 3-year warranty includes a 30-day DOA period covering manufacturing defects and faults. If a product becomes faulty within the first 30 days of purchase, it can be returned to Target under the 30-Day DOA agreement, at which point we will replace it where possible, or offer account credit. If it becomes faulty after the first 30 days the product will be repaired or replaced with a graded unit. Account credit will be unavailable outside of the 30-day DOA agreement. The end user will need to return it to the reseller they purchased it from originally. If the unit is found faulty within the first 30 days of purchase, it can be returned to the reseller to claim under DOA with Target - a proof of end-user purchase WILL be required.
Warranty Instructions: RESELLERS - please raise a Target RMA.
END USERS - in the first instance, please return it to the reseller you originally purchased it. Target is unable to deal with end-user warranty issues. In the event an end-user is unable to contact the reseller, they must contact Gigabyte directly via Gigabyte Returns.
Warranty Information: https://www.gigabyte.com/uk/Support/Consumer/Warranty
Warranty Contact: Gigabyte Returns
| DESIGN | |
|---|---|
| Form factor | Full-Height/Full-Length (FH/FL) |
| Product colour | Silver |
| Illumination | Yes |
| Number of fans | 3 fan(s) |
| Cooling type | Active |
| Illumination colour | Multi |
| Bracket height | Full-Height (FH) |
| Cooling technology | GIGABYTE WINDFORCE 3X | ENERGY MANAGEMENT |
| Minimum system power supply | 450 W |
| Supplementary power connectors | 1x 8-pin | MEMORY |
| Graphics card memory type | GDDR6 |
| Data transfer rate | 20 Gbit/s |
| Memory bus | 128 bit |
| Memory clock speed | 20000 MHz |
| Discrete graphics card memory | 16 GB | PACKAGING CONTENT |
| Manual | Yes | PACKAGING DATA |
| Package weight | 1.29 kg |
| Package depth | 354 mm |
| Package height | 75 mm |
| Package width | 182.5 mm |
| Manual | Yes |
| Package type | Box | PERFORMANCE |
| TV tuner integrated | No |
| DirectX version | 12.0 |
| OpenGL version | 4.6 |
| Dual Link DVI | No |
| Warranty period | 3 year(s) |
| Overclocked (OC) edition | Yes | PORTS & INTERFACES |
| Interface type | PCI Express 5.0 |
| DVI-I ports quantity | 0 |
| DVI-D ports quantity | 0 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1b |
| DisplayPorts quantity | 2 |
| DisplayPort version | 2.1a | PROCESSOR |
| Graphics processor | Radeon RX 9060 XT |
| Maximum resolution | 7680 x 4320 pixels |
| Parallel processing technology support | Not supported |
| Stream processors | 2048 |
| Maximum displays per videocard | 3 |
| CUDA | No |
| Graphics processor family | AMD |
| Processor boost clock speed | 3320 MHz |
| Processor boost clock speed (Gaming mode) | 2780 MHz | SYSTEM REQUIREMENTS |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 | TECHNICAL DETAILS |
| Warranty period | 3 year(s) | WEIGHT & DIMENSIONS |
| Weight | 840 g |
| Height | 118 mm |
| Depth | 40 mm |
| Length | 281 mm |
