High-resolution support
Experience detail and clarity with support for up to 7680 x 4320 resolution at 60 Hz, making it ideal for professional design and video editing tasks

Advanced connectivity
Equipped with 5 Mini DisplayPorts and a USB-C port, this graphics card offers versatile connectivity options for a multi-monitor setup or high-speed data devices

Powerful performance
With a 256-bit memory interface and GDDR6 SDRAM technology, it delivers a bandwidth of 448 GBps, ensuring smooth and efficient handling of complex graphics tasks

Advanced technology
Leveraging RDNA Architecture and 7 nm process technology, the AMD Radeon Pro W5700 provides exceptional performance and energy efficiency for professional applications.

Enhanced visual experience
Supports 10-bit color and AMD Radeon Pro Image Boost, offering a vivid and accurate color display, crucial for graphic design and content creation.

Bus Type
PCI Express 4.0 x16

Graphics Engine
AMD Radeon Pro W5700

Memory
8 GB GDDR6

Stream Processors
2304

Memory Interface
256-bit

Max Resolution
7680 x 4320

Max Monitors Supported
6

Interfaces Details
5 x Mini DisplayPort � USB-C

API Supported
DirectX 12, OpenCL 2.0, OpenGL 4.6, Vulkan 1.1, Shader Model 5.1

Dimensions (WxDxH)
26.7 cm x 11.2 cm

Manufacturer's Website:

www.amd.co.uk

Warranty:

AMD Processors in a box (PIB): 3 Year Limited Manufacturer Warranty.

Coverage

Year 1: Return to Target or AMD for warranty service.

Years 2-3: Warranty service provided directly by AMD

AMD Warranty Support

AMD Warranty Portal: https://www.amd.com/en/registration/warranty-services-portal.html

Please Note: First-time users must create an AMD account to access warranty services.

AMD Help & Support: https://www.amd.com/en/support.html

Required Documentation for AMD Warranty Claims

1. Product details including serial number and model number.

2. Clear explanation of the problem you're experiencing

3. Proof of purchase (receipt or invoice).

4. Photo of the CPU

DESIGN
Product colour	Blue
Cooling type	Active
Fan diameter	26.7 cm
Bracket height	Full-Height (FH)
ENERGY MANAGEMENT
Power consumption (typical)	205 W
Supplementary power connectors	1x 6-pin, 1x 8-pin
LOGISTICS DATA
Harmonized System (HS) code	84733020
MEMORY
Graphics card memory type	GDDR6
Bandwidth	448 GHz
Memory bus	256 bit
Discrete graphics card memory	8 GB
PERFORMANCE
DirectX version	12.0
OpenGL version	4.6
OpenCL version	2.0
PORTS & INTERFACES
Interface type	PCI Express x16 4.0
DVI-I ports quantity	0
HDMI ports quantity	0
Mini DisplayPorts quantity	5
DisplayPort version	1.4
USB Type-C ports quantity	1
PROCESSOR
Graphics processor	Radeon Pro W5700
Stream processors	2304
Graphics processor family	AMD
TECHNICAL DETAILS
Harmonized System (HS) code	84733020
