Device Protection
PoE Adapters are highly reliable, and when used with Ubiquiti TOUGHCable, they provide earth grounding and surge protection to help protect against electrostatic discharge (ESD) events.

Convenient Wall-Mounting
The 24V, 0.5A models, POE-24-12W and POE-24-12W-G, are wall-mountable using the optional wall-mount brackets.

Seamless airGateway Compatibility
The 15V, 0.8A and 24V, 0.5A models, POE-15-12W, POE-24-12W and POE-24-12W-G, work with the airGateway to bridge airMAX connections to Wi-Fi at customer locations.

Warranty:

Contact Ubiquiti Technical Support via https://rma.ubnt.com/ and obtain RMA reference. Call Target Customer Services with RMA reference to arrange repair/replacement. Warranty valid for 12 months from date of purchase.

CERTIFICATES
Certification	IC, UL
Compliance certificates	CE, Federal Communications Commission (FCC)
ENERGY MANAGEMENT
Input voltage	100 - 240 V
Input frequency	50/60 Hz
Input current	0.75 A
Output current	1 A
Power over Ethernet (PoE) voltage	24 V
FEATURES
Certification	IC, UL
Plug and Play	Yes
Product colour	White
Surge protection	Yes
NETWORKING
Power over Ethernet (PoE)	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
OPERATIONAL CONDITIONS
Operating relative humidity (H-H)	5 - 95%
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
PORTS & INTERFACES
Ethernet LAN (RJ-45) ports	2
RJ-45 input ports	1
RJ-45 output ports	1
SUSTAINABILITY
Sustainability compliance	Yes
Sustainability certificates	CE, Federal Communications Commission (FCC)
TECHNICAL DETAILS
Sustainability compliance	Yes
Sustainability certificates	CE, Federal Communications Commission (FCC)
Compliance certificates	CE, Federal Communications Commission (FCC)
WEIGHT & DIMENSIONS
Weight	166 g
Height	35 mm
Width	62 mm
Depth	96 mm
