| Speed | Gigabit |
| Ports | 16 |
| POE Capability | No |
| Managed or Unmanaged | Managed |
| Rack Mountable | Optional - Kit Required |
| Speed | Gigabit |
| Ports | 16 |
| POE Capability | No |
| Managed or Unmanaged | Managed |
| Rack Mountable | Optional - Kit Required |
| CERTIFICATION | |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA) | DATA TRANSMISSION |
| MAC address table | 16000 entries |
| Switching capacity | 84 Gbit/s |
| Jumbo frames support | Yes |
| Forwarding rate | 62 Mpps |
| Packet buffer memory | 1.5 MB |
| Static route | Yes |
| Throughput | 42 Gbit/s | DESIGN |
| Rack mounting | Yes |
| Form factor | 1U |
| LED indicators | Link, Network, Speed, Status |
| Product colour | Grey |
| Stackable | Yes |
| Reset button | Yes |
| Housing material | SGCC |
| Display type | LCM | ENERGY MANAGEMENT |
| Power source | AC/DC |
| Input voltage | 4.8 - 5.2 V |
| Redundant power supply (RPS) support | Yes |
| Input current | 5 A |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Power consumption (max) | 25 W |
| Power supply included | Yes | MANAGEMENT FEATURES |
| Switch layer | L3 |
| Quality of Service (QoS) support | Yes | NETWORKING |
| Networking standards | IEEE 802.1x |
| Flow control support | Yes |
| Port mirroring | Yes |
| Link aggregation | Yes |
| Broadcast storm control | Yes |
| Rate limiting | Yes |
| Number of VLANs | 1000 |
| VLAN support | Yes |
| 10G support | Yes |
| Virtual LAN features | Voice VLAN |
| IPv4 routes | 512 | OPERATIONAL CONDITIONS |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -5 - 40 °C |
| Heat dissipation | 85.3 BTU/h | OTHER FEATURES |
| Input voltage | 4.8 - 5.2 V | PACKAGING CONTENT |
| Cables included | Power |
| Rack mount kit | Yes | PACKAGING DATA |
| Cables included | Power |
| Rack mount kit | Yes | PERFORMANCE |
| Fanless | Yes | PORTS & INTERFACES |
| Gigabit Ethernet (copper) ports quantity | 12 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| SFP+ module slots quantity | 2 |
| Power connector | AC/DC |
| 2.5G Ethernet (copper) ports quantity | 4 | POWER OVER ETHERNET (POE) |
| Power over Ethernet (PoE) | No | SECURITY |
| Access Control List (ACL) | Yes |
| IGMP snooping | Yes |
| Authentication type | IEEE 802.1x |
| Loop protection | Yes |
| DHCP features | DHCP guarding, DHCP relay, DHCP server, DHCP snooping | TECHNICAL DETAILS |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA) | WEIGHT & DIMENSIONS |
| Weight | 1.95 kg |
| Height | 43.7 mm |
| Width | 325.1 mm |
| Depth | 160 mm |
