| Speed | 10G |
| Ports | 52 |
| POE Capability | No |
| Managed or Unmanaged | Unmanaged |
| Rack Mountable | Yes |
| Speed | 10G |
| Ports | 52 |
| POE Capability | No |
| Managed or Unmanaged | Unmanaged |
| Rack Mountable | Yes |
| CERTIFICATION | |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA) | DATA TRANSMISSION |
| MAC address table | 128000 entries |
| Switching capacity | 920 Gbit/s |
| Jumbo frames support | Yes |
| Forwarding rate | 684 Mpps |
| Packet buffer memory | 8 MB |
| Static route | Yes |
| Throughput | 460 Gbit/s | DESIGN |
| Rack mounting | Yes |
| Form factor | 1U |
| Backlight display | Yes |
| Product colour | Grey |
| Stackable | Yes |
| Reset button | Yes |
| Housing material | SGCC |
| Display type | LCM | ENERGY MANAGEMENT |
| Power source | AC/DC |
| Redundant power supply (RPS) support | Yes |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Power consumption (max) | 250 W |
| Power supply included | Yes | MANAGEMENT FEATURES |
| Switch layer | L2/L3 |
| Quality of Service (QoS) support | Yes |
| Switch type | Managed | MULTICAST FEATURES |
| Multicast support | Yes | NETWORKING |
| Flow control support | Yes |
| Port mirroring | Yes |
| Broadcast storm control | Yes |
| Rate limiting | Yes |
| Number of VLANs | 1000 |
| VLAN support | Yes |
| 10G support | Yes |
| Virtual LAN features | Interface-based VLAN, Voice VLAN |
| IPv4 routes | 256000 | OPERATIONAL CONDITIONS |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -5 - 40 °C | PACKAGING CONTENT |
| Cables included | Power |
| Rack mount kit | Yes | PACKAGING DATA |
| Cables included | Power |
| Rack mount kit | Yes | PORTS & INTERFACES |
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
| Basic switching RJ-45 Ethernet ports quantity | 48 |
| Power connector | AC/DC |
| SFP28 ports quantity | 4 |
| 2.5G Ethernet (copper) ports quantity | 16 |
| 10G Ethernet (copper) ports quantity | 32 | POWER OVER ETHERNET (POE) |
| Power over Ethernet (PoE) | No | SECURITY |
| IGMP snooping | Yes |
| Loop protection | Yes |
| Access Control List (ACL) IPv4 entries | 256 |
| DHCP features | DHCP guarding, DHCP relay, DHCP server, DHCPv6 snooping | TECHNICAL DETAILS |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA) | WEIGHT & DIMENSIONS |
| Weight | 7.5 kg |
| Height | 44 mm |
| Width | 442 mm |
| Depth | 480 mm |
