| Camera Resolution | 2688x1512 |
| Camera Type | Bullet |
| POE Capability | N/A |
| Pack Size | Single |
| Camera Resolution | 2688x1512 |
| Camera Type | Bullet |
| POE Capability | N/A |
| Pack Size | Single |
| AUDIO | |
|---|---|
| Built-in microphone | Yes | CAMERA |
| Lens viewing angle, horizontal | 84.4° |
| Lens viewing angle, vertical | 45.4° |
| Lens viewing angle, diagonal | 99.8° | DESIGN |
| Form factor | Bullet |
| Product colour | Black, White |
| Housing material | Aluminium, Polycarbonate (PC) |
| Mounting type | Wall/Pole |
| International Protection (IP) code | IP55 |
| IK code | IK04 | ENERGY MANAGEMENT |
| DC output voltage | 37, 57 |
| Power source type | PoE |
| Power consumption (max) | 4 W | IMAGE SENSOR |
| Sensor type | CMOS | LENS SYSTEM |
| Number of lenses | 1 | MANAGEMENT FEATURES |
| Reset button | Yes |
| Management software | UniFi Protect | NETWORKING |
| Ethernet LAN | Yes |
| Bluetooth | No |
| Wi-Fi | No |
| Ethernet interface type | Fast Ethernet | NIGHT VISION |
| LED type | IR |
| Night vision | Yes | OPERATIONAL CONDITIONS |
| Operating relative humidity (H-H) | 0 - 90% |
| Operating temperature (T-T) | -20 - 40 °C | PACKAGING CONTENT |
| Number of cameras | 1 | PERFORMANCE |
| Type | IP security camera |
| Processor model | ARM Cortex-A7 |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| Built-in processor | Yes |
| Infrared (IR) cut-off filter | Yes | PORTS & INTERFACES |
| Ethernet LAN (RJ-45) ports | 1 | SUSTAINABILITY |
| Sustainability compliance | Yes |
| Compliance certificates | CE, Federal Communications Commission (FCC) | TECHNICAL DETAILS |
| Sustainability compliance | Yes |
| Sustainability certificates | CE, Federal Communications Commission (FCC) |
| Compliance certificates | CE, Federal Communications Commission (FCC) | VIDEO |
| Maximum resolution | 2688 x 1512 pixels |
| Video compression formats | H.264, M-JPEG |
| Noise reduction | Yes |
| Frame rate | 30 fps |
| Supported graphics resolutions | 2688 x 1512 |
| Supported video modes | 1512p |
| Total megapixels | 4 MP |
| Image quality adjustment | Brightness, Contrast, Sharpness |
| Privacy masking | Yes |
| Text caption overlay | Yes |
| Noise reduction technology | 2D noise reduction, 3D noise reduction | WEIGHT & DIMENSIONS |
| Weight | 225 g |
| Length | 74.4 mm |
| Diameter | 7.55 cm |
