| Camera Resolution | 4K |
| Camera Type | Turret |
| POE Capability | 48v |
| Pack Size | Single |
| Camera Resolution | 4K |
| Camera Type | Turret |
| POE Capability | 48v |
| Pack Size | Single |
| AUDIO | |
|---|---|
| Built-in microphone | Yes | CAMERA |
| Angle of rotation | 360° |
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Lens viewing angle, horizontal | 109.9° |
| Lens viewing angle, vertical | 56.7° |
| Lens viewing angle, diagonal | 134.1° | DESIGN |
| Form factor | Turret |
| LED indicators | Yes |
| Product colour | White |
| Housing material | Aluminium, Polycarbonate (PC) |
| Mounting type | Ceiling/wall |
| International Protection (IP) code | IP66 |
| IK code | IK04 |
| Weatherproof | Yes | ENERGY MANAGEMENT |
| DC output voltage | 37, 42.5, 48, 54, 57 |
| Power source type | PoE |
| Power consumption (max) | 12.5 W | IMAGE SENSOR |
| Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") | MANAGEMENT FEATURES |
| Reset button | Yes | NETWORKING |
| Ethernet LAN | Yes |
| Bluetooth | No |
| Wi-Fi | No |
| Ethernet interface type | Fast Ethernet | NIGHT VISION |
| LED type | IR |
| Night vision | Yes |
| Night vision distance | 30 m | OPERATIONAL CONDITIONS |
| Operating relative humidity (H-H) | 0 - 90% |
| Operating temperature (T-T) | -30 - 50 °C | PACKAGING CONTENT |
| Manual | Yes |
| Mounting kit | Yes |
| Number of cameras | 1 |
| Screws included | Yes | PERFORMANCE |
| Type | IP security camera |
| Processor model | ARM Cortex-A53 |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| Built-in processor | Yes |
| Infrared (IR) cut-off filter | Yes | PORTS & INTERFACES |
| Ethernet LAN (RJ-45) ports | 1 | SECURITY |
| Human and vehicle targets classification | Yes | STORAGE |
| Built-in HDD | No | SUSTAINABILITY |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) | TECHNICAL DETAILS |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) | VIDEO |
| Maximum resolution | 3864 x 2160 pixels |
| Noise reduction | Yes |
| Frame rate | 30 fps |
| Total megapixels | 8 MP |
| Image quality adjustment | Brightness, Contrast, HDR, Sharpness |
| Text caption overlay | Yes |
| Noise reduction technology | 2D noise reduction, 3D noise reduction | WEIGHT & DIMENSIONS |
| Weight | 550 g |
| Height | 95 mm |
| Diameter | 10 cm |
