Looking for exceptional long-range Wi-Fi connectivity? Look no further than the Ubiquiti U6+ (U6-Plus) Long Range Wi-Fi 6 Wireless Access Point. This cutting-edge device is designed to provide reliable and high-performance wireless networking solutions for your home or business.
With its Wi-Fi 6 technology, the U6+ offers lightning-fast speeds and enhanced network capacity, enabling seamless streaming, gaming, and productivity across multiple devices simultaneously. Say goodbye to buffering and lagging!
Thanks to its long-range capabilities, the U6+ ensures a strong and stable wireless signal even in larger areas, such as offices, warehouses, or expansive homes. No more dead spots or weak connections – enjoy consistent coverage throughout your space.
Equipped with advanced features, the U6+ provides robust security protocols to protect your network and sensitive data. You can rest assured knowing your network is safeguarded against potential threats, ensuring peace of mind for both personal and professional use.
Installation and management of the U6+ are a breeze, thanks to Ubiquiti's user-friendly software interface. Easily set up and customize your network settings, monitor performance, and manage connected devices with ease. Experience hassle-free networking that adapts to your specific needs.
The Ubiquiti U6+ (U6-Plus) Long Range Wi-Fi 6 Wireless Access Point is a top-of-the-line solution that combines superior performance, extensive coverage, and advanced security features. Boost your Wi-Fi experience and take your connectivity to new heights. Upgrade to the U6+ and enjoy a seamless wireless experience like never before.
Specifications
Dimensions
160 x 33 mm (Ø6.3 x 1.3")
Weight
Without mount: 338 g (0.75 lb)
With mount: 413 g (0.91 lb)
Enclosure materials
Top cover: polycarbonate
Bottom cover: aluminum
Mount materials
ABS, SGCC steel
Networking interface
(1) GbE RJ45 port
Management interface
Ethernet
Power method
PoE
Supported voltage range
44–57V DC
Max. power consumption
9W
Max. TX power
2.4 GHz 23 dBm
5 GHz 23 dBm
MIMO
2x2
Throughput rate
2.4 GHz 573.5 Mbps
5 GHz 2402 Mbps
LED
White/blue
Button
Factory reset
Mounting
Wall/ceiling (included)
Operating temperature
-30 to 60° C (-22 to 140° F)
Operating humidity
5 to 95% noncondensing
Certications
CE, FCC, IC
WiFi standards
802.11a/b/g
WiFi 4/WiFi 5/WiFi 6
Wireless security
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID
8 per radio
VLAN
802.1Q
Advanced QoS
Per-user rate limiting
Guest traffic isolation
Supported
Zero wait DFS
Not supported
Concurrent clients
300+
Warranty:
Contact Ubiquiti Technical Support via https://rma.ubnt.com/ and obtain RMA reference. Call Target Customer Services with RMA reference to arrange repair/replacement.
Warranty valid for 12 months from date of purchase.
|
ANTENNA
|
| Antenna type |
Internal |
| Antenna gain level (max) |
5.4 dBi |
DESIGN
|
| Certification |
IC |
| LED indicators |
Y |
| Product colour |
White |
| Reset button |
Y |
| Housing material |
Aluminium, Polycarbonate (PC) |
| Placement |
Ceiling |
ENERGY MANAGEMENT
|
| Power over Ethernet (PoE) |
Y |
| DC voltage range |
44 - 57 V |
| Power consumption (max) |
9 W |
FEATURES
|
| Maximum data transfer rate |
2402 Mbit/s |
| Number of users |
300 user(s) |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q |
| Quality of Service (QoS) support |
Y |
| VLAN support |
Y |
| Maximum indoor range |
139.35 m |
| Transmitting power |
23 dBmW |
| 2.4 GHz |
Y |
| 5 GHz |
Y |
| MIMO |
Y |
| Maximum data transfer rate (2.4 GHz) |
573.5 Mbit/s |
| Maximum data transfer rate (5 GHz) |
2402 Mbit/s |
| 6 GHz |
N |
OPERATIONAL CONDITIONS
|
| Operating relative humidity (H-H) |
5 - 95% |
| Operating temperature (T-T) |
-30 - 60 °C |
PACKAGING CONTENT
|
| Number of products included |
1 pc(s) |
| Mounting kit |
Y |
PACKAGING DATA
|
| Number of products included |
1 pc(s) |
| Mounting kit |
Y |
PORTS & INTERFACES
|
| Ethernet LAN (RJ-45) ports |
1 |
| Internal RJ-45 ports quantity |
1 |
SECURITY
|
| Security algorithms |
WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA3-Enterprise |
SUSTAINABILITY
|
| Sustainability certificates |
CE, Federal Communications Commission (FCC) |
TECHNICAL DETAILS
|
| Sustainability certificates |
CE, Federal Communications Commission (FCC) |
WEIGHT & DIMENSIONS
|
| Weight |
338 g |
| Height |
33 mm |
| Width |
160 mm |
| Depth |
160 mm |
