| Type | Access Point |
| Speed | 4300Mbps |
| Indoor or Outdoor | Indoor |
| POE Capability | 48v |
| Pack Size | Single |
| Type | Access Point |
| Speed | 4300Mbps |
| Indoor or Outdoor | Indoor |
| POE Capability | 48v |
| Pack Size | Single |
| ANTENNA | |
|---|---|
| Antenna type | Internal |
| Antenna gain level (max) | 6 dBi | CERTIFICATION |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA) | DESIGN |
| LED indicators | Yes |
| Product colour | White |
| Reset button | Yes |
| Housing material | Aluminium, Polycarbonate (PC) |
| Placement | Ceiling, Wall | ENERGY MANAGEMENT |
| Power over Ethernet (PoE) | Yes |
| DC voltage range | 42.5 - 57 V |
| Power consumption (max) | 14 W | FEATURES |
| Maximum data transfer rate | 7300 Mbit/s |
| Frequency band | 2.4 - 5 GHz |
| Number of users | 300 user(s) |
| Networking standards | IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11be, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v |
| Rate limiting | Yes |
| Ethernet LAN data rates | 1000,2500 Mbit/s |
| VLAN support | Yes |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| MIMO | Yes |
| Fast roaming | Yes |
| Band steering | Yes |
| MIMO type | Multi User MIMO |
| Maximum data transfer rate (2.4 GHz) | 688 Mbit/s |
| Maximum data transfer rate (5 GHz) | 4300 Mbit/s |
| Fit AP mode features | Hotspot 2.0 |
| 6 GHz | No |
| Maximum Tx power (2.4 GHz) | 26 dBmW |
| Maximum Tx power (5 GHz) | 27 dBmW |
| Spatial streams | 5 |
| Coverage area | 160 m² |
| Wireless meshing | Yes | LOGISTICS DATA |
| Quantity per pack | 1 pc(s) | MANAGEMENT FEATURES |
| Access point management | Wi-Fi schedule | OPERATIONAL CONDITIONS |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -30 - 50 °C | PACKAGING CONTENT |
| Mounting kit | Yes |
| Quantity per pack | 1 pc(s) | PACKAGING DATA |
| Mounting kit | Yes | PORTS & INTERFACES |
| Ethernet LAN (RJ-45) ports | 1 | SECURITY |
| Security algorithms | PPSK, TLS |
| Remote Authentication Dial-In User Service (RADIUS) | Yes | TECHNICAL DETAILS |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA) | WEIGHT & DIMENSIONS |
| Weight | 448 g |
| Height | 43 mm |
| Width | 175.7 mm |
| Depth | 175.7 mm |
