| Type | Device Bridge |
| Speed | 400Mbps |
| Indoor or Outdoor | Indoor/Outdoor |
| POE Capability | 42.5/57v |
| Pack Size | Single |
| Type | Device Bridge |
| Speed | 400Mbps |
| Indoor or Outdoor | Indoor/Outdoor |
| POE Capability | 42.5/57v |
| Pack Size | Single |
| ANTENNA | |
|---|---|
| Antenna type | 2x2 |
| Antenna gain level (max) | 17 dBi |
| Antenna design | Internal | CERTIFICATES |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) | DATA TRANSMISSION |
| Maximum data transfer rate | 400 Mbit/s |
| Maximum transfer distance | 5000 m | ENERGY MANAGEMENT |
| Power over Ethernet (PoE) | Yes |
| Power source type | PoE |
| DC input voltage | 42.5 - 57 V |
| Power consumption (max) | 6 W | FEATURES |
| Material | Polycarbonate (PC) |
| LED indicators | LAN, Power |
| Product colour | White |
| Reset button | Yes |
| Mounting type | Pole |
| International Protection (IP) code | IPX6 |
| Product type | Network bridge | NETWORKING |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000 Mbit/s |
| Ethernet LAN interface type | Gigabit Ethernet | OPERATIONAL CONDITIONS |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -40 - 60 °C |
| Operating temperature (T-T) | -40 - 140 °F | PACKAGING CONTENT |
| Manual | Yes | PACKAGING DATA |
| Quantity per pack | 1 pc(s) | PORTS & INTERFACES |
| Connectivity technology | Wired & Wireless |
| Ethernet LAN (RJ-45) ports | 1 | SECURITY |
| Security algorithms | WPA2-AES | TECHNICAL DETAILS |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) | WEIGHT & DIMENSIONS |
| Weight | 782 g |
| Height | 360.9 mm |
| Width | 129.6 mm |
| Depth | 71.4 mm | WIRELESS LAN FEATURES |
| Wi-Fi | Yes |
| Wi-Fi band | Single-band (5 GHz) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Signal strength | 25 dBm |
