| Output Capacity | 3700 VA |
| Output Power | 3700W |
| Battery Type | N/A |
| Recharge Time (hours) | N/A |
| Output Capacity | 3700 VA |
| Output Power | 3700W |
| Battery Type | N/A |
| Recharge Time (hours) | N/A |
| CERTIFICATION | |
|---|---|
| Certification | EAC, EN 55022 class A, EN 55024, EN 61000-3-2, EN 61000-3-3, FCC part 15 class A, ICES-003, RCM, VDE | DESIGN |
| Type | Single-phase |
| Display | LCD |
| Product colour | Black |
| Mounting | Vertical |
| Rack capacity | 0U |
| On/off switch | No |
| PDU types | Switched | ENERGY MANAGEMENT |
| Output voltage | 230 V |
| Nominal output voltage | 239 V |
| Nominal input voltage | 230, 220 - 240 V |
| Maximum total current draw per phase | 16 A |
| Maximum input current per phase | 16 A |
| Maximum current | 16 A |
| Load capacity | 3680 VA |
| Maximum power | 3680 W |
| AC input frequency | 50 - 60 Hz | FEATURES |
| Certification | EAC, EN 55022 class A, EN 55024, EN 61000-3-2, EN 61000-3-3, FCC part 15 class A, ICES-003, RCM, VDE |
| Cable length | 3 m |
| Daisy chain | Yes | OPERATIONAL CONDITIONS |
| Operating altitude | 0 - 3048 m |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage temperature (T-T) | -25 - 65 °C |
| Operating temperature (T-T) | -5 - 45 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Non-operating altitude | 0 - 15240 m | PACKAGING DATA |
| Package weight | 8.59 kg |
| Package depth | 114 mm |
| Package height | 2002 mm |
| Package width | 165 mm | PORTS & INTERFACES |
| AC outlets quantity | 24 AC outlet(s) |
| Power plug | IEC 60309 |
| AC outlet types | C13 coupler, C19 coupler | WEIGHT & DIMENSIONS |
| Weight | 5.61 kg |
| Height | 1794 mm |
| Width | 55 mm |
| Depth | 46 mm |
