Target Components Ltd

WINDOWS 11 READY

Game with the Best
6 incredible cores for those who just want to game.

The Fastest in the Game
Get the high-speed gaming performance of the world's best desktop processor.

AMD StoreMI Technology
A fast and easy way to expand and accelerate the storage in a desktop PC with an AMD Ryzen processor.

AMD Ryzen Master Utility
The Simple and Powerful Overclocking Utility for AMD Ryzen processors.

AMD Ryzen VR-Ready Premium
For the best possible VR experiences, AMD offers select Ryzen VR-Ready Premium processors.

Features
AMD StoreMI Technology
AMD Ryzen Master Utility
AMD Ryzen VR-Ready Premium

CPU Type
AMD Ryzen 5

CPU Model
5600X
100-100000065BOX

Core Name
Zen 3

Socket
AM4

CPU Size
TSMC 7nm FinFET

PCI Express® Version
PCIe 4.0

Number of Cores
6

Number of Threads
12

Clock Speed
3.7GHz

Turbo Speed
4.6GHz

Unlocked Core Multiplier
Yes

Processor Graphics
N/A

GPU Core Speed
N/A

L1 Cache
N/A

L2 Cache
3MB

L3 Cache
32MB

Max TDP
65W

Heatsink
Wraith Stealth

Packaging
Retail

Manufacturer's Website:

www.amd.co.uk

Warranty:

3 Years Return to Manufacturer Warranty www.amd.com/warranty

FEATURES
PCI Express slots version	4.0
Market segment	Desktop
Harmonized System (HS) code	85423119
GRAPHICS
On-board graphics card model	Not available
Discrete graphics card model	Not available
On-board graphics card	No
Discrete graphics card	No
LOGISTICS DATA
Country of origin	China
Harmonized System (HS) code	85423119
MEMORY
Non-ECC	Yes
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	3200 MHz
PACKAGING DATA
Package weight	0.435 g
Package weight	435 g
PROCESSOR
Processor model	5600X
Processor manufacturer	AMD
Processor lithography	7 nm
Processor family	AMD Ryzen™ 5
Box	Yes
Processor socket	Socket AM4
Processor cores	6
Processor threads	12
Processor operating modes	64-bit
Processor boost frequency	4.6 GHz
Component for	PC
Processor cache	32 MB
Thermal Design Power (TDP)	65 W
Processor cache type	L3
Cooler included	Yes
Processor base frequency	3.7 GHz
Processor generation	AMD Ryzen 5000 Series
PROCESSOR SPECIAL FEATURES
Intel� Hyper Threading Technology (Intel� HT Technology)	No
WEIGHT & DIMENSIONS
Weight	350 g
Height	13.6 mm
Height	136 mm
Width	134 mm
Depth	7.2 mm
Depth	72 mm
