WINDOWS 11 READY

The Elite Gaming Processor
8 cores optimized for high-FPS gaming rigs.

The Fastest in the Game
Get the high-speed gaming performance of the world's best desktop processor.

AMD StoreMI Technology
A fast and easy way to expand and accelerate the storage in a desktop PC with an AMD Ryzen processor.

AMD Ryzen Master Utility
The Simple and Powerful Overclocking Utility for AMD Ryzen processors.

AMD Ryzen VR-Ready Premium
For the best possible VR experiences, AMD offers select Ryzen VR-Ready Premium processors.

Features
AMD StoreMI Technology
AMD Ryzen Master Utility
AMD Ryzen VR-Ready Premium

CPU Type
AMD Ryzen 7

CPU Model
5800X
100-100000063WOF

Core Name
Zen 3

Socket
AM4

CPU Size
TSMC 7nm FinFET

PCI Express Version
PCIe 4.0

Number of Cores
8

Number of Threads
16

Clock Speed
3.8GHz

Turbo Speed
4.7GHz

Unlocked Core Multiplier
Yes

Processor Graphics
N/A

GPU Core Speed
N/A

L1 Cache
N/A

L2 Cache
4MB

L3 Cache
32MB

Max TDP
105W

Heatsink
Not included

Packaging
Retail

Manufacturer's Website:

www.amd.co.uk

Warranty:

AMD Processors in a box (PIB): 3 Year Limited Manufacturer Warranty.

Coverage

Year 1: Return to Target or AMD for warranty service.

Years 2-3: Warranty service provided directly by AMD

AMD Warranty Support

AMD Warranty Portal: https://www.amd.com/en/registration/warranty-services-portal.html

Please Note: First-time users must create an AMD account to access warranty services.

AMD Help & Support: https://www.amd.com/en/support.html

Required Documentation for AMD Warranty Claims

1. Product details including serial number and model number.

2. Clear explanation of the problem you're experiencing

3. Proof of purchase (receipt or invoice).

4. Photo of the CPU

FEATURES
PCI Express slots version	4.0
Market segment	Desktop
Harmonized System (HS) code	85423119
GRAPHICS
On-board graphics card model	Not available
Discrete graphics card model	Not available
On-board graphics card	No
Discrete graphics card	No
LOGISTICS DATA
Country of origin	China
Harmonized System (HS) code	85423119
MEMORY
Non-ECC	Yes
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	3200 MHz
PACKAGING DATA
Package weight	120 g
Package type	Box
PROCESSOR
Processor model	5800X
Processor manufacturer	AMD
Processor lithography	7 nm
Processor family	AMD Ryzen™ 7
Box	Yes
Processor socket	Socket AM4
Package type	Box
Processor cores	8
Processor threads	16
Processor operating modes	64-bit
Processor boost frequency	4.7 GHz
Component for	PC
Processor cache	32 MB
Thermal Design Power (TDP)	105 W
Processor cache type	L3
Cooler included	No
Processor base frequency	3.8 GHz
Processor generation	AMD Ryzen 5000 Series
PROCESSOR SPECIAL FEATURES
Intel� Hyper Threading Technology (Intel� HT Technology)	No
WEIGHT & DIMENSIONS
Weight	0.114 g
Weight	114 g
Height	13.5 mm
Height	135 mm
Width	132 mm
Depth	7.5 mm
Depth	75 mm
