POWER. PERFORMANCE. EFFICIENCY. All at your fingertips with the technological innovation of the 5nm Zen4 core found inside AMD Ryzen 7000 Processors.

The Ultimate Gaming Processor
When your PC has an AMD Ryzen 7000 series processor, you can focus on what really matters; being victorious on the digital battlefield. With 8 cores, 16 threads and boost clocks of 5.3GHz this AMD Ryzen 7700 delivers game-changing performance.

Technology Design To Save You Time
AMD Ryzen 7000 series processors are built to beat the clock. With time-saving connectivity like PCIe 5.0 storage supports, ultra-fast WiFi 6E wireless, 16 processing threads and dedicated video encode/decode accelerators to elevate your creator experience with AMD Ryzen 7000 series processors.

Upgradeable For Years To Come
The all-new AMD Ryzen 7000 series processors come packed with the state-of-the-art technologies to keep you on the bleeding edge with the insane speed of DDR5 memory, jaw-dropping bandwidth with PCIe 5.0 supports, AMD EXPO one-touch memory overclocking and hyper-efficient 5nm manufacturing.

Built-in Radeon Graphics
This AMD Ryzen 7700 processor comes with integrated AMD Radeon Graphics, with a frequency of up to 2200MHz and dual cores, no external GPU is required!

Low Power Draw
The new Ryzen 7000 series processors have a TDP of just 65W, keeping temperatures cool and noise levels low.

Product Specifications

CPU Type
AMD Ryzen 7

CPU Model
7700
100-100000592WOF

Core Name
Zen 4

Socket
AM5

CPU Size
TSMC 5nm FinFET

Number of Cores
8

Number of Threads
16

Clock Speed
3.8GHz

Turbo Speed
5.3GHz

Unlocked Core Multiplier
Yes

Processor Graphics
Y

GPU Core Speed
2200 MHz

L1 Cache
N/A

L2 Cache
8MB

L3 Cache
32MB

Max TDP
65W

Heatsink
Yes, Wraith Prism LED.

Packaging
Retail

Manufacturer's Website:

www.amd.co.uk

Warranty:

3 Years Return to Manufacturer Warranty www.amd.com/warranty

FEATURES
Compatible operating systems	Windows 11 - 64-Bit Edition Windows 10 - 64-Bit Edition RHEL x86 64-Bit Ubuntu x86 64-Bit
PCI Express slots version	5.0
Market segment	Desktop
GRAPHICS
On-board graphics card model	AMD Radeon Graphics
Discrete graphics card model	Not available
On-board graphics card	Yes
On-board graphics card base frequency	400 MHz
On-board graphics card dynamic frequency (max)	2200 MHz
Discrete graphics card	No
MEMORY
ECC	Yes
Non-ECC	Yes
Memory channels	Dual-channel
Memory types supported by processor	DDR5-SDRAM
Memory clock speeds supported by processor	3600,5200 MHz
PROCESSOR
Processor model	7700
Processor manufacturer	AMD
Processor lithography	5 nm
Processor family	AMD Ryzen™ 7
Box	Yes
Processor socket	Socket AM5
Processor cores	8
Processor threads	16
Processor operating modes	64-bit
Processor boost frequency	5.3 GHz
Processor cache	32 MB
Thermal Design Power (TDP)	65 W
Processor cache type	L2 & L3
Cooler included	Yes
Processor base frequency	3.8 GHz
