TECHNOLOGY THAT SAVES YOU TIME
If you're in need of a powerful processor that's capable of handling heavy-duty tasks like 3D rendering, video exporting, or architectural visualisation? The AMD Ryzen 7000 Series processor is designed to give you the best possible performance and speed, making sure you can get more done in less time. With standout features such as support for PCIe 5.0 storage, letting you transfer files at lightning speed and ultra-fast Wi-Fi 6E giving you seamless internet connections.
EASY OVERCLOCKING
Bringing you smoother frame rates for your favourite games, the AMD Ryzen 7000 Series uses higher memory frequencies and more aggressive settings to unlock this, helping you accelerate your gaming experience with the AMD EXPO Technology.
LEADERSHIP EFFICIENCY
Whilst at the same power output the AMD Ryzen 7000 series processors deliver up to 49% more performance than the previous generation of processors. Use even less power thanks to the exclusive AMD Eco-Mode helping reduce your carbon footprint.
UNLOCKED OVERCLOCKING
With the ability to tweak and tune your AMD Ryzen processor for more personalised performance, control your processing power easily with one-click precision boost overdrive, or with the AMD Ryzen Master utility you can achieve this manually.
UPGRADABLE FOR YEARS TO COME
With the future in mind, AMD has committed to offering years of future support to the AM5 socket, making it possible for you to upgrade to technologies that have yet to be announced. Packed with current state-of-the-art technology that includes, high-speed DDR5 memory, PCIe 5.0 support, AMD EXPO one-touch memory overclocking, and hyper-efficient 5nm manufacturing. With an AMD Ryzen processor at the heart of your build, you can be assured you will be ready for the next step in gaming.
Specifications
CPU
12 Cores
Threads
24
Max Boost Clock
Up to 5.6GHz
Base Clock
4.4GHz
L1 Cache
768KB
L2 Cache
12MB
L3 Cache
128MB
CPU Socket
AM5
Max Operating Temperature
89 degrees C
OS Support
Windows 11 - 64-Bit Edition
Windows 10 - 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
Connectivity
PCI Express Version
PCIe 5.0
System Memory Type
DDR5
Memory Channels
2
Max Memory Speed
2x1R DDR5-5200
2x2R DDR5-5200
4x1R DDR5-3600
4x2R DDR5-3600
Graphics Capabilities
Graphics Model
AMD Radeon Graphics
Graphics Core Count
2
Graphics Frequency
2200 MHz
GPU Base
400 MHz
Warranty:
3 Years Return to Manufacturer Warranty www.amd.com/warranty
|
FEATURES
|
| Compatible operating systems |
Windows 11 - 64-Bit Edition
Windows 10 - 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit |
| Supported instruction sets |
AES, AVX, AVX 2.0, AVX-512, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSSE3 |
| PCI Express slots version |
5.0 |
GRAPHICS
|
| On-board graphics card model |
AMD Radeon Graphics |
| Discrete graphics card model |
Not available |
| On-board graphics card |
Yes |
| On-board graphics card base frequency |
400 MHz |
| On-board graphics card dynamic frequency (max) |
2200 MHz |
| Discrete graphics card |
No |
MEMORY
|
| ECC |
Yes |
| Non-ECC |
Yes |
| Memory channels |
Dual-channel |
| Maximum internal memory supported by processor |
128 GB |
| Memory types supported by processor |
DDR5-SDRAM |
| Memory clock speeds supported by processor |
3600,5200 MHz |
PROCESSOR
|
| Processor model |
7900X3D |
| Processor manufacturer |
AMD |
| Processor lithography |
5 nm |
| Processor family |
AMD Ryzen™ 9 |
| Box |
Yes |
| Processor socket |
Socket AM5 |
| Processor cores |
12 |
| Processor threads |
24 |
| Processor operating modes |
64-bit |
| Processor boost frequency |
5.6 GHz |
| Processor cache |
128 MB |
| Thermal Design Power (TDP) |
120 W |
| Processor cache type |
L3 |
| Cooler included |
No |
| Processor base frequency |
4.4 GHz |
| Processor generation |
AMD Ryzen 7000 Series |
PROCESSOR SPECIAL FEATURES
|
| Intel® Hyper Threading Technology (Intel® HT Technology) |
No |
