AMD Ryzen 9

CPU Model
7950X
100-100000514WOF

Core Name
Zen 4

Socket
AM5

CPU Size
TSMC 5nm FinFET

Number of Cores
16

Number of Threads
32

Clock Speed
4.5GHz

Turbo Speed
5.7GHz

Unlocked Core Multiplier
Yes

Processor Graphics
Y

GPU Core Speed
2200 MHz

L1 Cache
N/A

L2 Cache
16MB

L3 Cache
64MB

Max TDP
170W

Heatsink
No

Packaging
Retail

Manufacturer's Website:

www.amd.co.uk

Warranty:

3 Years Return to Manufacturer Warranty www.amd.com/warranty

FEATURES
Compatible operating systems	Windows 11 - 64-Bit, Windows 10 - 64-Bit, RHEL x86 64-Bit, Ubuntu x86 64-Bit
PCI Express slots version	5.0
GRAPHICS
On-board graphics card model	AMD Radeon Graphics
Discrete graphics card model	Not available
On-board graphics card	Yes
On-board graphics card base frequency	400 MHz
On-board graphics card dynamic frequency (max)	2200 MHz
Discrete graphics card	No
I/O CONFIGURATION
USB version	2.0/3.2 Gen 2 (3.1 Gen 2)
USB ports quantity	5
MEMORY
ECC	Yes
Non-ECC	Yes
Memory channels	Dual-channel
Maximum internal memory supported by processor	128 GB
Memory types supported by processor	DDR5-SDRAM
Memory clock speeds supported by processor	3600,5200 MHz
OPERATIONAL CONDITIONS
Maximum operating temperature	95 °C
OTHER FEATURES
L1 cache	1 MB
L2 cache	16000 KB
PROCESSOR
Processor model	7950X
Processor manufacturer	AMD
Processor family	AMD Ryzen™ 9
Box	Yes
Processor socket	Socket AM5
Processor cores	16
Processor threads	32
Processor operating modes	64-bit
Processor boost frequency	5.7 GHz
Processor cache	64 MB
Thermal Design Power (TDP)	170 W
Processor cache type	L3
Cooler included	No
Processor base frequency	4.5 GHz
PROCESSOR SPECIAL FEATURES
Intel� Hyper Threading Technology (Intel� HT Technology)	No
TECHNICAL DETAILS
Launch date	9/15/2022
