Specifications

Model & Type

CPU Type
AMD Ryzen Threadripper

CPU Model
5995WX

Socket
WRX8

Architecture
Zen 3

Manufacturing Process
7 nm

Cores & Clocks

No. of Cores
64 Core

No. of Threads
128

Clock Speed
2.7 GHz

Turbo Speed
4.5 GHz

Turbo Speed (On 1 Core)

Unlocked CPU
No

Bus Speeds

FSB/HT Speed

Memory Support

Max. Memory Size

Max. Memory Speed
DDR4 - 3200

Max. Memory Channels
Octa (8)

ECC Memory Support
Yes

Lanes & Features

Scalability
1 Socket/Processor ONLY

PCIe Lanes Supported

Integrated Graphics

Features Integrated Graphics
No

Integrated Graphics Model/Type
N/A

iGPU Compute Units
N/A

iGPU Cores/Streams
N/A

iGPU Clock
N/A

CPU Cache

L1 Cache
4MB

L2 Cache
32MB

L3 Cache
256MB

Smart Prefetch Cache

Thermals & Package

Max. TDP
280W

Thermal Specification
95 °C

Heatsink/Cooler Included?
Not Included, Sold Separately

Package Type
Retail

Additional Information

Scan Code
LN127286

Model Number
100-100000444WOF

GTIN
0730143314404

Manufacturer's Website:

www.amd.co.uk

Warranty:

3 Years Return to Manufacturer Warranty www.amd.com/warranty

FEATURES
PCI Express slots version	4.0
Market segment	Desktop
Harmonized System (HS) code	85423119
GRAPHICS
On-board graphics card model	Not available
Discrete graphics card model	Not available
On-board graphics card	No
Discrete graphics card	No
LOGISTICS DATA
Harmonized System (HS) code	85423119
MEMORY
Memory channels	Octa-channel
Memory types supported by processor	DDR4-SDRAM
PROCESSOR
Processor model	5995WX
Processor manufacturer	AMD
Processor lithography	7 nm
Processor family	AMD Ryzen Threadripper PRO
Box	Yes
Processor socket	Socket sWRX8
Processor cores	64
Processor threads	128
Processor operating modes	64-bit
Processor boost frequency	4.5 GHz
Processor cache	256 MB
Thermal Design Power (TDP)	280 W
Processor cache type	L3
Cooler included	No
Processor base frequency	2.7 GHz
Processor generation	AMD Ryzen Threadripper PRO 5000 WX-Series
