GAME WITHOUT COMPROMISE
Go beyond performance with the latest 14th Generation Intel Core processors, based on the Raptor-Lake Refresh Architecture with a hybrid-design incorporating a mixture of high performance P-Cores and efficient E-Cores. The i3-14100 comes in with up to 4 cores and up to 8 threads. Capable of reaching maximum clock speeds of 4.7GHz and providing incredible versatility with support for PCIe 5.0 components, DDR4 and DDR5 memory and All-New Wifi 7 connectivity. Be your Best with Intel.

REVOLUTIONARY PERFORMANCE AND MULTITASKING
Newly optimised hybrid architecture and industry-leading technology enable you to go beyond gaming and creation. From progressing in-game to advancing in real life, Intel® empowers you to be your best self.?

4 PERFORMANCE CORES
unleashes the capability to optimise the latest games and gaming software.

INTEL THREAD DIRECTOR
Keeps your gaming free of interruptions by making sure your background tasks never slow you down.


Specifications

Essentials
Product Collection:
Intel® Core™ i3 Processors (14th gen)

Vertical Segment:
Desktop

Processor Number:
i3-14100

Lithography:
Intel 7

Use Conditions:
PC/Client/Tablet

CPU Specifications

Total Cores:
4

# of Performance-cores:
4

# of Efficient-cores:
0

Total Threads:
8

Max Turbo Frequency:
4.7 GHz

Performance-core Max Turbo Frequency:
4.7 GHz

Performance-core Base Frequency:
3.5 GHz

Cache: 12 MB Intel® Smart Cache
Total L2 Cache:
5 MB

Processor Base Power:
60 W

Maximum Turbo Power:
110W

Supplemental Information

Marketing Status:
Launched

Launch Date:
Q1'24

Embedded Options Available:
Yes

Memory Specifications

Max Memory Size (dependent on memory type):
192 GB

Memory Types:
Up to DDR5 4800 MT/s, Up to DDR4 3200 MT/s

Max # of Memory Channels:
2

Max Memory Bandwidth:
76.8 GB/s

GPU Specifications

GPU Name?:
Intel® UHD Graphics 730

Graphics Max Dynamic Frequency:
1.5 GHz

Graphics Output:
eDP 1.4b, DP 1.4a, HDMI 2.1

Execution Units:
24

Max Resolution (HDMI):
4096 x 2160 @ 60Hz

Max Resolution (DP):
7680 x 4320 @ 60Hz

Max Resolution (eDP - Integrated Flat Panel):
5120 x 3200 @ 120Hz

DirectX Support:
12

OpenGL Support:
4.5

OpenCL Support:
3.0

Multi-Format Codec Engines:
1

Intel® Quick Sync Video:
Yes

Intel® Clear Video HD Technology:
Yes

# of Displays Supported:
4

Device ID:
0x4692

Expansion Options

Direct Media Interface (DMI) Revision:
4.0

Max # of DMI Lanes:
8

Scalability:
1S Only

PCI Express Revision:
5.0 and 4.0

PCI Express Configurations
: Up to 1x16+4, 2x8+4

Max # of PCI Express Lanes:
20

Package Specifications
TJUNCTION:
100°C

Package Size:
45.0 mm x 37.5 mm


Security & Reliability
Intel® Standard Manageability (ISM):
Yes

Intel® Control-Flow Enforcement Technology:
Yes

Intel® AES New Instructions:
Yes

Secure Key:
Yes

Intel® OS Guard:
Yes

Execute Disable Bit:
Yes

Intel® Boot Guard:
Yes

Mode-based Execute Control (MBEC):
Yes

Intel® Virtualization Technology (VT-x):
Yes

Intel® Virtualization Technology for Directed I/O (VT-d):
Yes

Intel® VT-x with Extended Page Tables (EPT):
Yes
