Intel Core i5 13500 2.5GHz 14 Core LGA 1700 Raptor Lake Processor, 20 Threads, 4.8GHz Boost, Intel UHD 770 Graphics

Key Specifications
Socket1700
On-Chip GraphicsYes
Speed2.5GHz
Core Quantity16
PrefixCore i5
Manufacturer : INTEL
EAN : 5032037260251
Manufacturer Part Code : BX8071513500
Weight : 0.46 kg
Login For Pricing

Key Specifications
Socket1700
On-Chip GraphicsYes
Speed2.5GHz
Core Quantity16
PrefixCore i5
Manufacturer :
INTEL

EAN :
5032037260251

Manufacturer Part Code :
BX8071513500

Weight :
0.46 kg
Recommended Products
1289Motherboards
See details
1451Liquid Cooling
See details
1287Air Cooling
See details

Ascend leaderboards, create worlds, and crunch numbers—all at once. Get next-generation performance for everything you do with the 13th Gen Intel Core processors. Do More with the Fastest Chip We've Ever Built.

Advancing Performance Hybrid Architecture
13th Gen Intel Core processors advances performance hybrid architecture with up to eight Performance-cores (P-core) and up to 16 Efficient-cores (E-core), combined with workloads intelligently routed by Intel® Thread Director.

Built for Modern Gaming
Built for gamers looking for maximum performance to play the latest games, while also having the capabilities to tackle other workloads. New 13th Gen Intel Core processor-based PCs make it all possible.

Superior Creating Experience
The 13th Gen Intel Core processor family offers faster P-cores and more E-cores with support for DDR4/DDR5 and PCIe 4.0/5.0. That provides a platform that can max out multitasking and choice for configurability.

Customize for What You Do Every Day
13th Gen Intel Core processors deliver highly flexible architecture and industry-leading tools for the ultimate in performance customization.

Level Up Your Game and Then Some
Built for modern gaming, streaming, and recording, Intel's performance hybrid architecture with up to eight Performance-cores and up to 16 Efficient-core makes it all possible.

Multitask with Ease
Superior performance, no matter what type of creator you are, lets you stream, browse, edit, video chat, and just take care of business. Buckle up because multitasking won't slow you down with the 13th Gen Intel Core processor.


Frequently Asked Questions

What are Performance-cores and Efficient-cores?

Performance-cores (P-cores):
- Are optimized to handle single and lightly threaded performance.
- Enhance gaming and productivity workload.

Efficient-cores (E-cores):
- Are optimized to handle scaling highly threaded workloads.
- Minimize interruptions from background task management.

What is Intel Thread Director?
Intel Thread Director sends the right workload to the right core at the right time. It helps prioritize and manage the distribution of workloads, sending tasks to the most optimized thread. This feature is on by default and works in tandem with the operating system for intelligent workload distribution. To get the full capabilities of Intel Thread Director, pair a select 13th Gen Intel Core desktop processor with Windows 11.


Specifications

Total Cores
14

# of Performance-cores
6

# of Efficient-cores
8

Total Threads
20

Max Turbo Frequency
4.80 GHz

Performance-core Max Turbo Frequency
4.80 GHz

Efficient-core Max Turbo Frequency
3.50 GHz

Performance-core Base Frequency
2.50 GHz

Efficient-core Base Frequency
1.80 GHz

Cache
24 MB Intel Smart Cache

Total L2 Cache
11.5 MB

Processor Base Power
65 W

Maximum Turbo Power
154 W

Max Memory Size (dependent on memory type)
128 GB

Memory Types
Up to DDR5 5600 MT/s
Up to DDR4 3200 MT/s

Max # of Memory Channels
2

Max Memory Bandwidth
89.6 GB/s

ECC Memory Supported
Yes

Processor Graphics
Intel UHD Graphics 770

Graphics Base Frequency
300 MHz

Graphics Max Dynamic Frequency
1.65 GHz

Graphics Output
eDP 1.4b, DP 1.4a, HDMI 2.1

Max Resolution (HDMI)
4096 x 2160 @ 60Hz

Max Resolution (DP)
7680 x 4320 @ 60Hz

Max Resolution (eDP - Integrated Flat Panel)
5120 x 3200 @ 120Hz

DirectX Support
12

OpenGL Support
4.5

OpenCL Support
3.0
Manufacturer's Website:
Warranty:
3 Years Manufacturers Warranty, Tel: 0870 607 2439
FEATURES
Supported instruction sets SSE4.1, SSE4.2, AVX 2.0
PCI Express slots version 5.0, 4.0
Execute Disable Bit Yes
Idle States Yes
Thermal Monitoring Technologies Yes
Scalability 1S
CPU configuration (max) 1
Embedded options available Yes
PCI Express configurations 1x16+1x4, 2x8+1x4
Maximum number of PCI Express lanes 20
Market segment Desktop
Harmonized System (HS) code 8542310001
Export Control Classification Number (ECCN) 5A992C
Commodity Classification Automated Tracking System (CCATS) 740.17B1
Use conditions PC/Client/Tablet, Workstation
Direct Media Interface (DMI) Revision 4.0
GRAPHICS
On-board graphics card model Intel UHD Graphics 770
Discrete graphics card model Not available
On-board graphics card Yes
On-board graphics card base frequency 300 MHz
On-board graphics card dynamic frequency (max) 1550 MHz
On-board graphics card outputs supported Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card maximum resolution (DisplayPort) 7680 x 4320 pixels
Number of execution units 32
On-board graphics card ID 0x4680
On-board graphics card maximum resolution (eDP - Integrated Flat Panel) 5120 x 3200 pixels
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) 120 Hz
On-board graphics card refresh rate at maximum resolution (DisplayPort) 60 Hz
On-board graphics card refresh rate at maximum resolution (HDMI) 60 Hz
Number of displays supported (on-board graphics) 4
On-board graphics card maximum resolution (HDMI) 4096 x 2160 pixels
On-board graphics card DirectX version 12.0
On-board graphics card OpenGL version 4.5
Discrete graphics card No
Multi-Format Codec Engines 2
LOGISTICS DATA
Harmonized System (HS) code 8542310001
MEMORY
ECC Yes
Memory bandwidth (max) 76.8 GB/s
Memory channels Dual-channel
Maximum internal memory supported by processor 192 GB
Memory types supported by processor DDR4-SDRAM, DDR5-SDRAM
OPERATIONAL CONDITIONS
Tjunction 100 °C
OTHER FEATURES
Maximum internal memory 192 GB
L2 cache 11776 KB
Graphics output eDP 1.4b, DP 1.4a, HDMI 2.1
PACKAGING DATA
Package type Retail box
PROCESSOR
Processor model i5-13500
Processor manufacturer Intel
Processor family Intel® Core™ i5
Box Yes
Processor socket LGA 1700
Processor cores 14
Processor threads 20
Processor operating modes 64-bit
Processor boost frequency 4.8 GHz
Processor cache 24 MB
Bus type DMI4
Processor codename Raptor Lake
Processor cache type Smart Cache
Memory bandwidth supported by processor (max) 76.8 GB/s
Processor ARK ID 230580
Efficient cores 8
Performance cores 6
Maximum number of DMI lanes 8
Processor base power 65 W
Maximum turbo power 154 W
Efficient-core base frequency 1.8 GHz
Efficient-core boost frequency 3.5 GHz
Performance-core base frequency 2.5 GHz
Performance-core boost frequency 4.8 GHz
Processor generation 13th gen Intel® Core™ i5
PROCESSOR SPECIAL FEATURES
IntelŽ Hyper Threading Technology (IntelŽ HT Technology) Yes
IntelŽ Turbo Boost Technology 2.0
IntelŽ Quick Sync Video Technology Yes
IntelŽ Clear Video HD Technology (IntelŽ CVT HD) Yes
IntelŽ AES New Instructions (IntelŽ AES-NI) Yes
Enhanced Intel SpeedStep Technology Yes
Intel Trusted Execution Technology Yes
IntelŽ Active Management Technology (IntelŽ AMT) Yes
Intel VT-x with Extended Page Tables (EPT) Yes
IntelŽ Secure Key Yes
Intel 64 Yes
Intel Stable Image Platform Program (SIPP) Yes
IntelŽ OS Guard Yes
Intel Virtualization Technology for Directed I/O (VT-d) Yes
Intel Virtualization Technology (VT-x) Yes
Intel Turbo Boost Max Technology 3.0 No
IntelŽ Speed Shift Technology Yes
IntelŽ Boot Guard Yes
IntelŽ vPro? Platform Eligibility Yes
Mode-based Execute Control (MBE) Yes
IntelŽ Deep Learning Boost (IntelŽ DL Boost) Yes
IntelŽ Volume Management Device (VMD) Yes
IntelŽ Control-flow Enforcement Technology (CET) Yes
IntelŽ Thread Director Yes
IntelŽ Gaussian & Neural Accelerator (IntelŽ GNA) 3.0 Yes
Intel vProŽ Enterprise Platform Eligibility Yes
IntelŽ Threat Detection Technology (TDT) Yes
IntelŽ Standard Manageability (ISM) Yes
IntelŽ One-Click Recovery Yes
IntelŽ Hardware Shield Eligibility Yes
IntelŽ Total Memory Encryption - Multi Key Yes
IntelŽ Virtualization Technology with Redirect Protection (VT-rp) Yes
Intel vProŽ Essentials Platform Eligibility Yes
IntelŽ Remote Platform Erase (RPE) Yes
TECHNICAL DETAILS
OpenCL version 3.0
Status Launched
Launch date Q1''23
Target market Gaming
WEIGHT & DIMENSIONS
Processor package size 45 x 37.5 mm
