| Case Style | Small Form Factor |
| Processor | Intel Core i5 |
| Processor Cores | 6 |
| Storage | 256GB |
| Memory | 8GB |
| Graphics | On-chip |
| Operating Software | Windows 11 Pro |
| Case Style | Small Form Factor |
| Processor | Intel Core i5 |
| Processor Cores | 6 |
| Storage | 256GB |
| Memory | 8GB |
| Graphics | On-chip |
| Operating Software | Windows 11 Pro |
| DESIGN | |
|---|---|
| Chassis type | SFF |
| Cable lock slot | Yes |
| Product colour | Black |
| Volume | 7.4 L |
| Cable lock slot type | Kensington |
| Colour name | Black | ENERGY MANAGEMENT |
| Power supply | 260 W |
| Power supply input voltage | 100 - 240 V | GRAPHICS |
| On-board graphics card model | Intel UHD Graphics 730 |
| Discrete graphics card model | Not available |
| On-board graphics card | Yes |
| Discrete graphics card | No |
| On-board GPU manufacturer | Intel | MEMORY |
| Internal memory type | DDR4-SDRAM |
| Memory slots | 2x DIMM |
| Maximum internal memory | 64 GB |
| Memory clock speed | 3200 MHz |
| Memory layout (slots x size) | 1 x 8 GB |
| Internal memory | 8 GB | NETWORKING |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Ethernet LAN data rates | 100,1000 Mbit/s | OPERATING SYSTEM/SOFTWARE |
| Operating system installed | Windows 11 Pro |
| Operating system architecture | 64-bit | OPERATIONAL CONDITIONS |
| Operating altitude | 0 - 3048 m |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating temperature (T-T) | 5 - 35 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Non-operating altitude | 0 - 12192 m | PACKAGING CONTENT |
| Contrast ratio (typical) | 10 - 90% |
| Display included | No |
| Mouse included | Yes |
| Keyboard included | Yes | PERFORMANCE |
| Motherboard chipset | Intel B660 |
| Audio system | High Definition Audio |
| Trusted Platform Module (TPM) | Yes |
| Number of speakers | 1 |
| Product type | PC |
| Audio chip | Realtek ALC623-CG | PORTS & INTERFACES |
| Line-out | Yes |
| USB 2.0 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| Microphone in | Yes |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Combo headphone/mic port | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 | PROCESSOR |
| Processor model | i5-12400 |
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i5 |
| Processor cores | 6 |
| Processor boost frequency | 4.4 GHz |
| Processor cache | 18 MB |
| Processor generation | 12th gen Intel® Core™ i5 | STORAGE |
| Optical drive type | No |
| Total storage capacity | 256 GB |
| Card reader integrated | Yes |
| SSD interface | PCI Express 4.0 |
| SSD capacity | 256 GB |
| Number of SSDs installed | 1 |
| Storage media | SSD |
| SSD form factor | M.2 |
| NVMe | Yes |
| Total SSDs capacity | 256 GB | SUSTAINABILITY |
| Sustainability certificates | TCO, RoHS | WEIGHT & DIMENSIONS |
| Weight | 4.5 kg |
| Height | 274.8 mm |
| Width | 100 mm |
| Depth | 308 mm |
