Tech Specs
Processor
Intel® Core™ i5-1335U, 10C (2P + 8E) / 12T, P-core 1.3 / 4.6GHz, E-core 0.9 / 3.4GHz, 12MB
Graphics
Integrated Intel® Iris® Xe Graphics
Chipset
Intel® SoC Platform
Memory
8GB Soldered LPDDR5-4800
Memory Slots
Memory soldered to systemboard, no slots, dual-channel
Max Memory
8GB soldered memory, not upgradable
Storage
256GB SSD M.2 2242 PCIe® 4.0x4 NVMe® Opal 2.0
Max Storage Support
One drive, up to 1TB M.2 2242 SSD
Storage Slot
One M.2 2242 PCIe® 4.0 x4 slot
Card Reader
No card reader
Optical
None
Audio Chip
High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers
Stereo speakers, 2W x2, Dolby Audio™ Premium
Camera
FHD 1080p + IR Hybrid with Privacy Shutter
Microphone
2x, Array
Battery
46Wh
Power Adapter
65W USB-C® (3-pin)
Display
13.3" WUXGA (1920x1200) IPS, 300nits, Anti-glare, 45% NTSC
Touchscreen
None
Keyboard
Backlit, English (UK)
Case Color
Thunder Black
Case Material
Aluminium (Top), GFRP (Bottom)
Pen
Pen Not Supported
Dimensions (WxDxH)
305 x 218 x 17.23 mm (12.0 x 8.58 x 0.68 inches)
Weight
Starting at 1.26 kg (2.78 lbs)
Operating System
Windows® 11 Pro, English
Bundled Software
None
WLAN + Bluetooth
Intel® Wi-Fi® 6 AX201, 802.11ax 2x2 + BT5.2
WWAN
WWAN Upgradable to 4G
SIM Card
None
Ethernet
No Onboard Ethernet
NFC
None
Standard Ports
1x USB 3.2 Gen 1
1x USB 3.2 Gen 1 (Always On)
1x USB-C® 3.2 Gen 2 (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4)
1x Thunderbolt™ 4 / USB4® 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4)
1x HDMI® 2.1, up to 4K/60Hz
1x Headphone / microphone combo jack (3.5mm)
Optional Ports (configured)
1x Smart Card Reader
1x Nano-SIM Card Slot
Docking
Various docking solutions supported via Thunderbolt™ or USB-C®
(See Docking for ThinkPad® L13 Gen 4 (Intel®) for compatible options)
Smart Card Reader
Smart Card Reader
Security Chip
Discrete TPM 2.0 Enabled
Fingerprint Reader
Touch Style, Match-on-Chip, Integrated in Power Button
Physical Locks
Kensington® Nano Security Slot™, 2.5 x 6 mm
Other Security
Camera privacy shutter
IR camera for Windows® Hello (facial recognition)
System Management
Non-vPro®
Base Warranty
1-year, Courier or Carry-in
Included Upgrade
1Y Premier WHB (CPN)
Bundled Accessories
None
Green Certifications
ENERGY STAR® 8.0
EPEAT™ Gold Registered
ErP Lot 6/26
RoHS compliant
TCO Certified 9.0
Mil-Spec Test
MIL-STD-810H military test passed
Warranty:
1 Year Manufacturers Carry-In Warranty, Tel: 03337773991 Lenovo will first go through some fault finding/troubleshooting routines to see if they can solve the problem.
Within DOA Period: Lenovo will issue an authorisation number for return to the dealer/distributor.
Outside DOA Period: Lenovo will issue an RMA number and will handle the warranty direct with the end user (unless otherwise instructed).
This DOA period can vary so please verify this information with the manufacturer.
The item will have a base warranty when you first receive it. A base warranty is the manufacturing warranty to protect the product once it leaves the factory. Once the product is purchased and registered, the base warranty is deactivated and switches to the full consumer warranty providing the level of service that is included with the machine.
AUDIO
|
Audio system |
Dolby Audio Premium |
Built-in microphone |
Yes |
Speaker power |
2 W |
Number of built-in speakers |
2 |
Number of microphones |
2 |
Audio chip |
Realtek ALC3287 |
BATTERY
|
Battery technology |
Lithium Polymer (LiPo) |
Fast charging |
Yes |
Battery capacity (Watt-hours) |
46 Wh |
CAMERA
|
Front camera |
Yes |
Front camera resolution |
1920 x 1080 pixels |
Privacy camera |
Yes |
Privacy type |
Privacy shutter |
Front camera HD type |
Full HD |
Infrared (IR) camera |
Yes |
CERTIFICATES
|
Certification |
MIL-STD-810H |
Compliance certificates |
RoHS |
DESIGN
|
Form factor |
Clamshell |
Product colour |
Black |
Housing material |
Aluminium |
Product type |
Laptop |
Colour name |
Thunder Black |
DISPLAY
|
Contrast ratio (typical) |
800:1 |
Display diagonal |
33.8 cm (13.3") |
Contrast ratio (typical) |
5 - 95% |
Display brightness |
300 cd/m² |
Display resolution |
1920 x 1200 pixels |
Touchscreen |
No |
LED backlight |
Yes |
Anti-glare screen |
Yes |
Native aspect ratio |
16:10 |
HD type |
WUXGA |
Colour gamut |
45% |
Panel type |
IPS |
RGB colour space |
NTSC |
ENERGY MANAGEMENT
|
AC adapter input voltage |
100 - 240 V |
AC adapter frequency |
50 - 60 Hz |
AC adapter power |
65 W |
USB Power Delivery (USB PD) |
Yes |
USB Type-C charging port |
Yes |
GRAPHICS
|
On-board graphics card model |
Intel Iris Xe Graphics |
Discrete graphics card model |
Not available |
On-board graphics card |
Yes |
Discrete graphics card |
No |
On-board graphics card family |
Intel Iris Xe Graphics |
On-board GPU manufacturer |
Intel |
KEYBOARD
|
Pointing device |
ThinkPad UltraNav |
Numeric keypad |
No |
Spill-resistant keyboard |
Yes |
Keyboard language |
UK English |
Keyboard backlit |
Yes |
MEMORY
|
Internal memory type |
LPDDR5-SDRAM |
Maximum internal memory |
8 GB |
Memory clock speed |
4800 MHz |
Memory form factor |
On-board |
Memory channels |
Dual-channel |
Internal memory |
8 GB |
NETWORKING
|
Wi-Fi standards |
Wi-Fi 6 (802.11ax) |
Bluetooth version |
5.1 |
Ethernet LAN |
No |
Antenna type |
2x2 |
Bluetooth |
Yes |
WWAN |
Upgradable |
Near Field Communication (NFC) |
No |
Mobile network connection |
No |
Top Wi-Fi standard |
Wi-Fi 6 (802.11ax) |
WLAN controller model |
Intel Wi-Fi 6 AX201 |
WLAN controller manufacturer |
Intel |
OPERATING SYSTEM/SOFTWARE
|
Operating system installed |
Windows 11 Pro |
Operating system architecture |
64-bit |
Operating system language |
English |
OPERATIONAL CONDITIONS
|
Operating altitude |
0 - 3048 m |
Operating relative humidity (H-H) |
8 - 95% |
Storage temperature (T-T) |
5 - 43 °C |
Operating temperature (T-T) |
5 - 35 °C |
Storage relative humidity (H-H) |
5 - 95% |
Maximum shipping altitude |
3048 m |
OTHER FEATURES
|
AC adapter included |
Yes |
PACKAGING CONTENT
|
AC adapter included |
Yes |
PERFORMANCE
|
Motherboard chipset |
Intel SoC |
PORTS & INTERFACES
|
USB 2.0 ports quantity |
0 |
HDMI ports quantity |
1 |
HDMI version |
2.1 |
Combo headphone/mic port |
Yes |
USB Sleep-and-Charge |
Yes |
USB Sleep-and-Charge ports |
1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
USB Type-C DisplayPort Alternate Mode |
Yes |
USB Power Delivery |
Yes |
Thunderbolt 4 ports quantity |
1 |
Intel® Thunderbolt 4 |
Yes |
PROCESSOR
|
Processor model |
i5-1335U |
Motherboard chipset |
Intel SoC |
Processor manufacturer |
Intel |
Processor family |
Intel® Core™ i5 |
Processor cores |
10 |
Processor boost frequency |
4.6 GHz |
Processor cache |
12 MB |
Configurable TDP-down |
12 W |
Processor cache type |
Smart Cache |
Efficient cores |
8 |
Performance cores |
2 |
Processor generation |
13th gen Intel® Core™ i5 |
Efficient-core Max Turbo Frequency |
3.4 GHz |
Performance-core Max Turbo Frequency |
4.6 GHz |
PROCESSOR SPECIAL FEATURES
|
CPU configuration (max) |
1 |
SECURITY
|
Cable lock slot |
Yes |
Trusted Platform Module (TPM) |
Yes |
Fingerprint reader |
Yes |
Password protection type |
Power on, Supervisor, SSD |
Trusted Platform Module (TPM) version |
2.0 |
Cable lock slot type |
Kensington |
Password protection |
Yes |
Smart card reader |
Yes |
Windows Hello |
Yes |
STORAGE
|
Optical drive type |
No |
Total storage capacity |
256 GB |
Card reader integrated |
No |
SSD interface |
PCI Express 4.0 |
SSD capacity |
256 GB |
Number of SSDs installed |
1 |
Storage media |
SSD |
SSD form factor |
M.2 |
NVMe |
Yes |
Total SSDs capacity |
256 GB |
SUSTAINABILITY
|
Sustainability certificates |
TCO, ENERGY STAR, EPEAT Gold, ErP |
WEIGHT & DIMENSIONS
|
Weight |
1.26 kg |
Height |
17.2 mm |
Width |
305 mm |
Depth |
218 mm |
