PERFORMANCE
Processor
AMD Ryzen™ 3 7330U (4C / 8T, 2.3 / 4.3GHz, 2MB L2 / 8MB L3)
Graphics
Integrated AMD Radeon™ Graphics
Chipset
AMD SoC Platform
Memory
8GB Soldered DDR4-3200
Memory Slots
One memory soldered to systemboard, one DDR4 SO-DIMM slot, dual-channel capable
Max Memory
Up to 40GB (8GB soldered + 32GB SO-DIMM) DDR4-3200
Storage
256GB SSD M.2 2242 PCIe® 4.0x4 NVMe® Opal 2.0
Storage Slot
Two M.2 slots
• One M.2 2242 PCIe® 3.0 x4 slot
• One M.2 2280 PCIe 3.0 x4 slot
Max Storage Support
Up to two drives, 2x M.2 SSD
• M.2 2242 SSD up to 512GB
• M.2 2280 SSD up to 1TB
Optical
None
Card Reader
No card reader
Audio Chip
High Definition (HD) Audio, Synaptic® CX11880 codec
Speakers
Stereo speakers, 2W x2, Dolby Atmos®
Microphone
2x, Array
Camera
HD 720p with Privacy Shutter
Battery
57Wh
Power Adapter
65W USB-C® (3-pin)
DESIGN
Display
14" WUXGA (1920x1200) IPS, 300 nits, Anti-glare, 45% NTSC
Touchscreen
None
Screen-to-Body Ratio
90%
Pen
Pen Not Supported
Keyboard
Backlit, English (UK)
Dimensions (W x D x H)
313 x 219.3 x 17.99 mm (12.32 x 8.63 x 0.71 inches)
Weight
Starting at 1.43 kg (3.15 lbs)
Case Color
Graphite Black
Case Material
Aluminium (Top), Aluminium (Bottom)
SOFTWARE
Operating System
Windows® 11 Pro, English
Bundled Software
None
CONNECTIVITY
WLAN + Bluetooth
Wi-Fi® 6, 802.11ax 2x2 + Bluetooth® 5.1
WWAN
Non-WWAN
SIM Card
None
Ethernet
100/1000M (RJ-45)
NFC
None
Standard Ports
1x USB 3.2 Gen 1
1x USB 3.2 Gen 1 (Always On)
1x USB-C® 3.2 Gen 1 (supports data transfer, Power Delivery 3.0, and DisplayPort™ 1.4)
1x USB-C® 3.2 Gen 2 (supports data transfer, Power Delivery 3.0, and DisplayPort™ 1.4)
1x HDMI® 1.4b
1x Headphone / Microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
Docking
Various docking solutions supported via USB-C®.
For more compatible docking solutions, please visit Docking for ThinkPad® E14 Gen 5 (AMD)
SECURITY & PRIVACY
Security Chip
Discrete TPM 2.0 Enabled
Physical Locks
Kensington® Nano Security Slot, 2.5 x 6 mm
Smart Card Reader
None
Fingerprint Reader
None
Other Security
Camera Privacy Shutter
ThinkShield
MANAGEABILITY
System Management
Non-DASH
SERVICE
Base Warranty
1-year, Courier or Carry-in
Included Upgrade
None
ACCESSORIES
Bundled Accessories
None
CERTIFICATIONS
Green Certifications
ENERGY STAR® 8.0
EPEAT™ Gold Registered
ErP Lot 6/26
RoHS compliant
TCO Certified 9.0
Mil-Spec Test
MIL-STD-810H military test passed
Other Certifications
TUV Rheinland® Low Blue Light (Software Solution)
Warranty:
1 Year Manufacturers Carry-In Warranty, Tel: 03337773991 Lenovo will first go through some fault finding/troubleshooting routines to see if they can solve the problem.
Within DOA Period: Lenovo will issue an authorisation number for return to the dealer/distributor.
Outside DOA Period: Lenovo will issue an RMA number and will handle the warranty direct with the end user (unless otherwise instructed).
This DOA period can vary so please verify this information with the manufacturer.
The item will have a base warranty when you first receive it. A base warranty is the manufacturing warranty to protect the product once it leaves the factory. Once the product is purchased and registered, the base warranty is deactivated and switches to the full consumer warranty providing the level of service that is included with the machine.
There are currently no data sheets available for this product.
