PERFORMANCE
Processor
Intel® Core™ i5-1235U, 10C (2P + 8E) / 12T, P-core 1.3 / 4.4GHz, E-core 0.9 / 3.3GHz, 12MB
Graphics
Integrated Intel® Iris® Xe Graphics
Chipset
Intel® SoC Platform
Memory
16GB Soldered LPDDR4x-4266
Memory Slots
Memory soldered to systemboard, no slots, dual-channel (8GB or 16GB models)
Max Memory
16GB soldered memory, not upgradable
Storage
512GB SSD M.2 2242 PCIe® 4.0x4 NVMe®
Storage Slot
One M.2 2280 PCIe® 4.0 x4 slot
Max Storage Support
One drive, up to 1TB M.2 2242 SSD or 512GB M.2 2280 SSD
Card Reader
SD Card Reader
Audio Chip
High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers
Front-facing stereo speakers, 2W x2, optimized with Dolby Audio™
Microphone
2x, Array
Camera
FHD 1080p with Privacy Shutter
Battery
52.5Wh
Power Adapter
65W Round Tip (3-pin)
DESIGN
Display
14" WUXGA (1920x1200) IPS 300nits Glossy, 45% NTSC, 60Hz, TÜV Low Blue Light, Glass, Touch
Touchscreen
10-point Multi-touch
Pen
Lenovo® Digital Pen
Keyboard
Backlit, English (UK)
Touchpad
Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)
Dimensions (W x D x H)
313.1 x 224.9 x 17.4 mm (12.32 x 8.85 x 0.69 inches)
Weight
Starting at 1.5 kg (3.31 lbs)
Case Color
Storm Grey
Case Material
Aluminium (Top), PC-ABS + 40% GF (Bottom)
Surface Treatment
Aluminium Stamping (Anodized with Sandblasting)
SOFTWARE
Operating System
Windows® 11 Home, English
Bundled Software
Office Trial
CONNECTIVITY
WLAN + Bluetooth
Wi-Fi® 6, 802.11ax 2x2 + BT5.2
WWAN
Non-WWAN
Ethernet
No Onboard Ethernet
NFC
None
Standard Ports
1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
1x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 3.0 and DisplayPort™ 1.4a
1x HDMI® 1.4b
1x Headphone / microphone combo jack (3.5mm)
1x SD card reader
1x Power connector
Docking
Various docking solutions are supported via Thunderbolt™.
For more compatible docking solutions, please visit Docking for IdeaPad® Flex 5 14IAU7
SECURITY & PRIVACY
Security Chip
Firmware TPM 2.0
Fingerprint Reader
Touch Style, on Palm Rest
Other Security
Camera privacy shutter
SERVICE
Base Warranty
1-year, Courier or Carry-in
Included Upgrade
None
ACCESSORIES
Bundled Accessories
None
CERTIFICATIONS
Green Certifications
ENERGY STAR® 8.0
ErP Lot 6/26
RoHS compliant
Other Certifications
Models with 2.8K OLED, WUXGA panel:
TUV Rheinland® Low Blue Light (Software Solution)
Warranty:
1 Year Manufacturers Carry-In Warranty, Tel: 03337773991 Lenovo will first go through some fault finding/troubleshooting routines to see if they can solve the problem.
Within DOA Period: Lenovo will issue an authorisation number for return to the dealer/distributor.
Outside DOA Period: Lenovo will issue an RMA number and will handle the warranty direct with the end user (unless otherwise instructed).
This DOA period can vary so please verify this information with the manufacturer.
The item will have a base warranty when you first receive it. A base warranty is the manufacturing warranty to protect the product once it leaves the factory. Once the product is purchased and registered, the base warranty is deactivated and switches to the full consumer warranty providing the level of service that is included with the machine.
