| Type | Router |
| Speed | 1200 Mbps |
| PoE | No |
| Type | Router |
| Speed | 1200 Mbps |
| PoE | No |
| ANTENNA | |
|---|---|
| Antenna gain level (max) | 5 dBi |
| Antennas quantity | 4 |
| Antenna design | External | DESIGN |
| LED indicators | Status |
| Product colour | Black |
| Product type | Tabletop router | MANAGEMENT FEATURES |
| Web-based management | Yes |
| Reset button | Yes |
| WPS push button | Yes |
| MIMO | Yes |
| MU-MIMO technology | Yes | MOBILE NETWORKING |
| 3G | No |
| 4G | No |
| SIM card slot | No |
| 5G | No | NETWORKING |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN | Yes |
| Receiver sensitivity | 11g 6Mbps: -96dBm 11g 54Mbps: -78dBm 11n HT40 MCS7: -74dBm 11n HT20 MCS7: -71dBm 11a 6Mbps: -97dBm 11a 54Mbps: -79dBm 11ac VHT20 MCS8: -74dBm 11ac VHT40 MCS9: -70dBm 11ac VHT80 MCS9: -65dBm |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN interface type | Gigabit Ethernet | OPERATIONAL CONDITIONS |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating temperature (T-T) | Yes | PACKAGING CONTENT |
| AC adapter included | Yes |
| Cables included | LAN (RJ-45) |
| Quick installation guide | Yes |
| Antenna included | Yes | PACKAGING DATA |
| AC adapter included | Yes |
| Cables included | LAN (RJ-45) |
| Package type | Box |
| Quick installation guide | Yes |
| Antenna included | Yes | PORTS & INTERFACES |
| Ethernet LAN (RJ-45) ports | 3 |
| DC-in jack | Yes |
| USB port | No | POWER |
| External power adapter | Yes |
| Power source type | AC | PROTOCOLS |
| Supported network protocols | PPPoE/L2TP/PPTP |
| DHCP client | Yes |
| DHCP server | Yes | SECURITY |
| Security algorithms | WPA-PSK, WPA2-PSK |
| Firewall security | SPI Firewall, IP/MAC Address Binding |
| NAT functionality | Port Forwarding, Port Triggering, UPnP, DMZ |
| Access Control List (ACL) | Yes |
| Parental control | Yes |
| Network address translation (NAT) | Yes |
| Firewall | Yes |
| Guest access | Yes | WAN CONNECTION |
| WAN connection type | RJ-45 |
| DSL WAN | No |
| Ethernet WAN | Yes |
| SIM card slot | No |
| 3G/4G USB modem compatibility | No | WEIGHT & DIMENSIONS |
| Height | 37.1 mm |
| Width | 159.7 mm |
| Depth | 125.9 mm | WIRELESS LAN FEATURES |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| WLAN data transfer rate (max) | 1167 Mbit/s |
| WLAN data transfer rate (first band) | 300 Mbit/s |
| WLAN data transfer rate (second band) | 867 Mbit/s |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
