| CERTIFICATION | |
|---|---|
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS | ENERGY MANAGEMENT |
| Input voltage | 3.3 V | FEATURES |
| Form factor | SFP+ |
| Product colour | Silver |
| Hot-Plug support | Yes |
| Easy to install | Yes |
| Housing material | Metal | LOGISTICS DATA |
| Quantity per pack | 1 pc(s) | OPERATIONAL CONDITIONS |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating temperature (T-T) | 0 - 70 °C |
| Maximum operating temperature | 70 °C |
| Minimum operating temperature | 0 °C | PACKAGING CONTENT |
| Quantity per pack | 1 pc(s) | PACKAGING DATA |
| Package weight | 2.87 kg |
| Package depth | 122.5 mm |
| Package height | 38.5 mm |
| Package width | 81.5 mm | PERFORMANCE |
| Interface type | RJ-45 |
| Maximum data transfer rate | 10300 Mbit/s |
| Ethernet LAN | Yes |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3an, IEEE 802.3bz |
| Ethernet interface type | 10 Gigabit Ethernet |
| Copper ethernet cabling technology | 10GBASE |
| Maximum transfer distance | 100 m |
| SFP transceiver type | Copper | SUSTAINABILITY |
| Sustainability compliance | Yes | TECHNICAL DETAILS |
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS | WEIGHT & DIMENSIONS |
| Height | 13.8 mm |
| Width | 67.4 mm |
| Depth | 13.8 mm |
