| Ports | 16 Ports |
| Managed/Unmanaged | Unmanaged |
| Speed | 10/100/1000 |
| PoE capable | No |
| Ports | 16 Ports |
| Managed/Unmanaged | Unmanaged |
| Speed | 10/100/1000 |
| PoE capable | No |
| DATA TRANSMISSION | |
|---|---|
| MAC address table | 8000 entries |
| Switching capacity | 32 Gbit/s |
| Full duplex | Y |
| MAC address table | 8000 entries |
| Jumbo frames support | Yes |
| Number of queues | 4 |
| Store-and-forward | Yes |
| Switching capacity | 32 Gbit/s |
| Forwarding rate | 23.81 Mpps |
| Packet buffer memory | 4.1 MB |
| Jumbo frames | 9000 |
| Jumbo frames support | Y |
| Number of queues | 4 |
| Store-and-forward | Y |
| Number of VLANs | 32 |
| 10G support | N |
| Forwarding rate | 23.81 Mpps |
| Packet buffer memory | 4.1 MB |
| Jumbo frames | 9000 | DESIGN |
| Rack mounting | No |
| LED indicators | Yes |
| Wall mountable | Yes |
| Product colour | Black |
| Rack mounting | N |
| LED indicators | Y |
| Wall mountable | Y |
| Housing material | Metal |
| Colour of product | Black |
| Housing material | Metal | ENERGY MANAGEMENT |
| Input current | 0.6 A |
| Heat dissipation | 31.68 BTU/h |
| AC input frequency | 50 Hz |
| AC input voltage | 220 V |
| DC input voltage | 9 V |
| Power consumption (max) | 9.3 W |
| Power supply included | Yes |
| Power over Ethernet (PoE) Support | N |
| Input current | 0.6 A |
| AC input frequency | 50 Hz |
| AC input voltage | 220 V |
| DC input voltage | 9 V |
| Power consumption (max) | 9.3 W |
| Power supply included | Y | ILLUMINATION/ALARMS |
| LED indicators | Y | LOGISTICS DATA |
| Harmonized System (HS) code | 85176990 | MANAGEMENT FEATURES |
| Quality of Service (QoS) support | Yes |
| Switch type | Unmanaged |
| Quality of Service (QoS) support | Y |
| Switch type | Unmanaged | MEMORY |
| Packet buffer memory | 4.1 MB | NETWORKING |
| Full duplex | Yes |
| Networking standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Full duplex | Y |
| MAC address table | 8000 entries |
| Flow control support | Yes |
| Port mirroring | Yes |
| Link aggregation | Yes |
| Broadcast storm control | Yes |
| Rate limiting | Yes |
| Networking standards | IEEE 802.1Q,IEEE 802.1p,IEEE 802.3,IEEE 802.3ab,IEEE 802.3u |
| Auto MDI/MDI-X | Yes |
| Number of VLANs | 32 |
| VLAN support | Yes |
| 10G support | No |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Cable types supported | Cat3, Cat4, Cat5, Cat5e, Cat6 |
| Flow control support | Y |
| Auto-negotiation | Yes |
| Cable length detection | Yes |
| Port mirroring | Y |
| Link aggregation | Y |
| Jumbo Frames support | Y |
| Broadcast storm control | Y |
| Virtual LAN features | Protocol-based VLAN, Tagged VLAN |
| Store-and-forward | Y |
| Rate limiting | Y |
| IGMP snooping | Y |
| Auto MDI/MDI-X | Y |
| Number of VLANs | 32 |
| VLAN support | Y |
| 10G support | N |
| Copper ethernet cabling technology | 10BASE-T,100BASE-TX,1000BASE-T |
| Cable types supported | Cat3,Cat4,Cat5,Cat5e,Cat6 |
| Auto-negotiation | Y |
| Cable length detection | Y |
| Virtual LAN features | Protocol-based VLAN,Tagged VLAN | OPERATIONAL CONDITIONS |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Heat dissipation | 31.68 BTU/h |
| Operating relative humidity range | 10 - 90% |
| Storage temperature range (T-T) | -40 - 70 °C |
| Operating temperature range (T-T) | 0 - 40 °C |
| Storage relative humidity range | 5 - 90% |
| Heat dissipation | 31.68 BTU/h | PACKAGING CONTENT |
| Cables included | AC |
| Quick start guide | Yes |
| Cables included | AC |
| Quick start guide | Y | PACKAGING DATA |
| Cables included | AC |
| Quick start guide | Yes |
| Cables included | AC |
| Quick start guide | Y | PERFORMANCE |
| Harmonized System (HS) code | 85176990 |
| Packet buffer memory | 4.1 MB |
| Auto-negotiation | Y | PORTS & INTERFACES |
| Gigabit Ethernet (copper) ports quantity | 16 |
| Installed SFP+ modules quantity | 0 |
| Installed SFP modules quantity | 0 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Gigabit Ethernet (copper) ports quantity | 16 |
| Copper ethernet cabling technology | 10BASE-T,100BASE-TX,1000BASE-T |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 16 | POWER OVER ETHERNET (POE) |
| Power over Ethernet (PoE) | No |
| Power over Ethernet (PoE) support | N | SECURITY |
| IGMP snooping | Yes |
| Loop protection | Yes |
| IGMP snooping | Y |
| Loop protection | Y | TECHNICAL DETAILS |
| Rack mounting | N |
| Colour of product | Black |
| Number of queues | 4 |
| Housing material | Metal |
| VLAN support | Y | VIRTUAL LAN FEATURES |
| Number of VLANs | 32 |
| VLAN support | Y |
| Virtual LAN features | Protocol-based VLAN,Tagged VLAN | WEIGHT & DIMENSIONS |
| Height | 25.4 mm |
| Width | 286 mm |
| Depth | 111.7 mm |
| Height | 25.4 mm |
| Width | 286 mm |
| Depth | 111.7 mm |
