| Connection A | HDMI (M) |
| Connection B | HDMI (M) |
| None | |
| Length | 5m |
| Colour | Black & Red |
| Connection A | HDMI (M) |
| Connection B | HDMI (M) |
| None | |
| Length | 5m |
| Colour | Black & Red |
| FEATURES | |
|---|---|
| Certification | RoHS, REACH, UL |
| Cable length | 5 m |
| Cable type | Round cable |
| Colour depth | 8 bit |
| Data transfer rate | 18 Gbit/s |
| Maximum resolution | 4096 x 2160 pixels |
| Product colour | Black |
| Connector material | Nickel |
| Supported graphics resolutions | 4096 x 2160 |
| HDMI version | 2.0 |
| Connector 1 | HDMI Type A (Standard) |
| Connector 2 | HDMI Type A (Standard) |
| Connector contacts plating | Gold |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| AWG wire size | 30 |
| Cable material | Copper-clad steel (CCS) |
| HDMI Ethernet channel | Yes |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Cable jacket material | Polyvinyl chloride (PVC) |
| Quantity per pack | 1 pc(s) |
| Shield material | Aluminium |
| Bending radius (min) | 6 cm |
| Contact material | Phosphor bronze |
| Colour sampling | 4:4:4 |
| Nominal attenuation | 300kHz-825MHz 5dB, 825MHz-2.475GHz 5dB, 2.475GHz-4.125GHz 12dB, 4.125GHz-5.1GHz 20dB |
| Connector housing material | Polyvinyl chloride (PVC) | LOGISTICS DATA |
| Harmonized System (HS) code | 84733080 | OPERATIONAL CONDITIONS |
| Storage temperature (T-T) | -10 - 80 °C |
| Operating temperature (T-T) | -10 - 80 °C | WEIGHT & DIMENSIONS |
| Package type | Polybag |
| Cable diameter | 6 mm |
| Connector 1 dimensions (WxDxH) | 19.2 x 34.1 x 10.6 mm |
| Connector 2 dimensions (WxDxH) | 19.2 x 34.1 x 10.6 mm |
