USB3.1 brings many improvements to the previous standard USB3.0. The most noticeable is the new Type-C connector which is much smaller than the previous standard connectors, it is also reversible.

Another feature is called Alternative Mode. This allows the USB to carry different types of signal. Our cable adapters will use this mode and convert the DP Alt mode signal in to a HDMI signal.

Specifications
Supports USB-C input and HDMI output
Supports DisplayPort 1.2 Altmode
Supports per lane data rates of 2.7Gbps (HBR) and 1.62Gbps (RBR)
Supports content protection of HDCP
Supports HDMI resolution max up to 4k@60Hz
USB bus power (no external power supply)
1 Meter

Warranty:

1 Year Return To Base Warranty

Return-to-Base warranty returns are processed within 14 business days of confirmed date of receipt - see our Returns Policy for more information.

FEATURES
Cable length	1 m
Data transfer rate	2.7 Gbit/s
Product colour	Black
Supported video modes	2160p
HDCP	Yes
Connector 1	USB Type-C
Connector 2	HDMI Type A (Standard)
Maximum refresh rate	60 Hz
Connector 1 form factor	Straight
Connector 2 form factor	Straight
Connector 1 gender	Male
Connector 2 gender	Male
LOGISTICS DATA
Harmonized System (HS) code	84733080
PACKAGING CONTENT
Quantity per pack	1 pc(s)
PACKAGING DATA
Quantity per pack	1 pc(s)
TECHNICAL DETAILS
Harmonized System (HS) code	84733080
