| Connection Type | Cable |
| Wireless Standard | 1500Mbps |
| Connection Type | Cable |
| Wireless Standard | 1500Mbps |
| ANTENNA | |
|---|---|
| Antenna gain level (max) | 5 dBi |
| Antennas quantity | 4 |
| Detachable antenna(s) | No |
| Antenna design | External | DESIGN |
| LED indicators | Power, WLAN |
| Wall mountable | Yes |
| Product colour | Black |
| Product type | Tabletop router | MANAGEMENT FEATURES |
| Reset button | Yes |
| WPS push button | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| MU-MIMO technology | Yes | MOBILE NETWORKING |
| SIM card slot | No | NETWORKING |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Port forwarding | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Port triggering | Yes |
| Number of guest networks (5 GHz) | 1 |
| Number of guest networks (2.4 GHz) | 1 | OPERATIONAL CONDITIONS |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating temperature (T-T) | Yes | PACKAGING CONTENT |
| AC adapter included | Yes |
| Cables included | LAN (RJ-45) |
| Quick installation guide | Yes | PACKAGING DATA |
| AC adapter included | Yes |
| Cables included | LAN (RJ-45) |
| Quick installation guide | Yes | PORTS & INTERFACES |
| Ethernet LAN (RJ-45) ports | 3 |
| USB port | No | POWER |
| Power source type | DC | PROTOCOLS |
| DHCP client | Yes |
| DHCP server | Yes | SECURITY |
| Security algorithms | WPA, WPA2, WPA3 |
| Firewall security | SPI Firewall, IP and MAC Address Binding |
| Access Control List (ACL) | Yes |
| DMZ support | Yes |
| Network address translation (NAT) | Yes |
| Firewall | Yes | WAN CONNECTION |
| WAN connection type | RJ-45 |
| DSL WAN | No |
| Ethernet WAN | Yes |
| SIM card slot | No |
| 3G/4G USB modem compatibility | No | WEIGHT & DIMENSIONS |
| Height | 45 mm |
| Width | 175.6 mm |
| Depth | 157.2 mm | WIRELESS LAN FEATURES |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| WLAN data transfer rate (max) | 1500 Mbit/s |
| WLAN data transfer rate (first band) | 1201 Mbit/s |
| WLAN data transfer rate (second band) | 300 Mbit/s |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
